| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| ENGINE GROUP | ||||
| POWERTRAIN INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | 58E-06-03040 | ALTERNATOR/BLOWER ASSEMBLY(SEE INDEX) | 1 | 64211 |
| 2 | TJ5933 | ADAPTER ASSEMBLY | 1 | |
| TM3466 | SHIM-1/250" | 4 | ||
| TM3467 | SHIM-1/250" | 4 | ||
| TM3468 | SHIM-1/143" | 4 | ||
| TM3469 | SHIM-1/143" | 4 | ||
| TW6616 | SHIM-1/100" | 12 | ||
| VN9087 | CAPSCREW-5/8”-11NC×21/2"(FLYWHEEL) | 12 | ||
| VW5737 | CAPSCREW-5/8"-11NC×2"(DRILLEDHEAD) | 12 | ||
| WA0361 | FLAT WASHER-5/8" | 24 | ||
| 3 | PC3180 | ENGINE(ORDER FROMFACTORY) | 1 | |
| 4 | XB8365 | SUB-FRAME | 1 | |
| Item | Part No | Description | Qty uom | |
| 1 | GE0413 | COVER | 1 | |
| 2 | TC1234 | CAPSCREW-3/8"-16NCX3/4" | 12 | |
| 3 | VE4687 | LOCKWASHER-3/8" | 12 | |
| 4 | XA5635 | PLATE,FRONT | 1 | |
| 5 | VE4739 | CAPSCREW-3/8"-16NCX1" | 6 | |
| 6 | VE4515 | FLAT WASHER-3/8" | 12 | |
| 7 | GE0796 | LOCKNUT-3/8"-16NC | 6 | |
| 8 | VS7026 | LATCH,COVER | 2 | |
| 9 | GE1083 | COVER ASSEMBLY | 2 | |
| 10 | GE1173 | GASKET | 2 | |
| 11 | VJ2672 | CEMENT( QUART) | AS REQUIRED | |
| (SEEFOLLOWING PAGES FOR BALANCE OF ALTERNATOR/BLOWER ASSEMBLY COMPONENT PARTS.) |
||||
| ENGINE/SUB-FRAME MOUNTS | ||||
| Item | Part No | Description | Qty | |
| 1 | WB1193 | CAPSCREW-M20×2.50×90 | 2 | |
| 2 | MM0475 | LOCKWASHER-M20 | 2 | |
| 3 | VN6450 | CAPSCREW-3/8"-16NCX7/8" | 4 | |
| 4 | C1547 | FLAT WASHER-3/8" | 4 | |
| 5 | 58E-49-00000 | COVER,TRUNNION | 1 | |
| 6 | C1645 | CAPSCREW-3/4"-10NC×21/4" | 6 | |
| 7 | C1542 | LOCKWASHER-3/4" | 6 | |
| 8 | C5542 | CAPSCREW-11/4"-7NCX3" | 2 | |
| 9 | WA0366 | FLAT WASHER-11/4" | 2 | |
| 10 | VM3891 | BUSHING,RUBBER | 2 | |
| 11 | TY8058 | PIVOT,ENGINE | 1 | |
| 12 | TY8055 | PIN,PIVOT | ||
| Item | Part No | Description | Qty | |
| 1 | MM0075 | CAPSCREW-M20X2.50X60 | 14 | |
| 2 | MM0475 | LOCKWASHER-M20 | 16 | |
| 3 | VW2236 | SETSCREW,HALF DOG | 4 | |
| 4 | E5222 | JAM NUT-3/4”-10NC | 4 | |
| 5 | TN1018 | PLATE | 2 | |
| 6 | TN1019 | PIN | 2 | |
| 7 | PB4177 | RACE,INNER | 2 | |
| 8 | EK9065 | CRADLE-RH | 1 | |
| 58E-01-00040 | CRADLE-LH | 1 | ||
| 9 | VN9079 | CAPSCREW-1"-8NCX21/4" | 8 | |
| 10 | C1544 | LOCKWASHER-1" | 8 | |
| Item | Part No | Description | Qty | |
| 1 | VM6531 | CAP,ENGINE MOUNTING | 2 | |
| 2 | VM3891 | BUSHING,RUBBER | 2 | |
| 3 | E4477 | CAPSCREW-3/4"-10NCX13/8"(TAPER HEAD) | 12 | |
| 4 | MM0178 | NUT-M10×1.50 | 2 | |
| 5 | MM0471 | LOCKWASHER-M10 | 2 | |
| ENGINE FILTERS | ||||
| ltem | Part No | Description | Qty | |
| 1 | ELIMINATOR FILTER ASSEMBLY | 1 | ||
| 2 | XA2134 | ELEMENT,WATER CORROSION RESISTOR | 2 | |
| 3 | XA4881 | ELEMENT,FUEL FILTER(ON ENGINE) | 3 | |
| NS | NOTE:NS =NOT SHOWN | |||
| NS | XA4488 | PUMP,PRELUBE | 1 | |
| ITEM | PART NUMBER | DESCRIPTION | QTY | |
| 1 | XA5867 | BELT ALTERNATOR | 1 | |
| 2 | 58E-08-00450 | KIT ALTERNATOR GUARD | 1 | |
| Item | Part No | Description | Qty | |
| 1 | PB7997 | CLAMP,V-BAND | 3 | |
| 2 | MM0618 | CAPSCREW-M12×1.75×30 | 8 | |
| 3 | MM0472 | LOCKWASHER-M12 | 2 | |
| 4 | MM0462 | FLAT WASHER-M12 | 2 | |
| 5 | EJ8384 | HANGER | 1 | |
| 6 | EM6766 | TUBE(LH) | ||
| 7 | TA6490 | CLAMP ASSEMBLY | 6 | |
| TA6483 | CLAMP | |||
| TA6491 | U-BOLT-3/8"-16NC | 1 | ||
| C0312 | LOCKWASHER-3/8" | 2 | ||
| C1521 | NUT-3/8"-16NC | 2 | ||
| 8 | EL6205 | ROD,THREADED | 1 | |
| 9 | C1632 | CAPSCREW-5/8"-11NCX21/2" | 24 | |
| 10 | VC1390 | LOCKWASHER-5/8" | 24 | |
| 11 | C1525 | NUT-5/8"-11NC | 24 | |
| 12 | EM9897 | TUBE(RH) | 1 | |
| 13 | WA0471 | CAPSCREW-1/2"-13NC×21/4" | 6 | |
| 14 | WA4728 | FLAT WASHER-1/2" | 12 | |
| 15 | DF3500 | LOCKNUT-1/2"-13NC | 6 | |
| 16 | TL8151 | JAM NUT-1/2"-20NF | 6 | |
| 17 | EJ9909 | CLAMP | 3 | |
| 18 | PC1247 | ROD END,FEMALE | 6 | |
| 19 | MM0624 | CAPSCREW-M12×1.75×70 | 8 | |
| 20 | EJ1952 | CLAMP(BOTTOM) | 4 | |
| 21 | EJ8390 | TUBE | 2 | |
| 22 | EJ8380 | HANGER,MUFFLER | 2 | |
| 23 | MM0694 | LOCKNUT-M12×1.75 | 6 | |
| 24 | EH9967 | MUFFLER | 2 | |
| 25 | XB2383 | TUBE | 1 | |
| 26 | EJ2480 | TUBE | 1 | |
| 27 | EB4763 | TUBE | ||
| 28 | EK1736 | ROD,THREADED | ||
| 29 | EM6772 | ROD,THREADED | ||
