| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| 17EA33J304 |
| 17EA33J306 |
| 17EA33J320 |
| 17EA33J370 |
| 17EA33J420 |
| 17EA33J565 |
| 17EA33J651 |
| 17EA33J732 |
| 17EA33J747 |
| 17EA33J900 |
| 17EA33J945 |
| 17EA33J965 |
| 17EA33J1160 |
| CONTROL GROUP MODEL17KG535B1 See On-Line Master for Current Revision | |||
| PART NO. | QTY | DESCRIPTION | |
| 17KG535B1 | 1 | CONTROLGROUP(SEE PB-60029-003) | |
| 41A296327ALP2 | 3 | CONTACTOR (SEEPB-65020-003) | |
| 17FM796A1 | 14 | POSITIVE IGBT MODULE PANEL | |
| 17FM797A1 | 14 | NEGATIVE IGBT MODULE PANEL | |
| 41A296302CDP2 | 10 | CAPACITOR,IGBT INVERTER | |
| 41A296328AKP2 | 4 | SENSOR,AC-DC CURRENT | |
| 17FM702A1 | 2 | PANEL ASSEMBLY(VAM) | |
| 41A296321BSP1 | 13 | FUSE,IGBT SWITCHASSEMBLY | |
| 41B566971G1 | 5 | SUPPRESSION MODULE | |
| 41C666558G1 | 2 | PANEL | |
| 84A215344P1 | 8 | PLUG | |
| 17FL386A1 | 1 | ICP2 PANEL | |
| 41A296352CYP2 | 2 | POWER CONVERTER,IGBT GATE DRIVER(LRU) | |
| 17FM689A1 | 1 | PANEL(SEE PB-74126-007) | |
| 41C668507G1 | 1 | AMBIENT AIR TEMPERATURE PANEL | |
| 41A267497P2 | TERMINAL BOARD,2 POLE | ||
| 41A296328AFP2 | SENSOR,THERMISTOR,100,000 OHM | ||
| 17BC17E1 | TERMINAL BOARD (SEE PB-77000-005) | ||
| 41A317303ACP1 | PRESSURE SENSOR,BAROMETRIC(BPT),0-15 PSIA | ||
| 84B510632G1 | FUSE PANEL | ||
| 41A296321BEP1 | FUSE LIMITER,50 AMP | ||
| 84B516032G1 | DIODE ASSEMBLY | ||
| 41C667531G1 | CAPACITORASSEMBLY | ||
| 41A296302BBP1 | CAPACITOR,120,000 UFD,75 VOLT | ||
| 41B569100G1 | CLAMP,CAPACITOR | ||
| 41A326087G1 | SUPPORT,CAPACITOR | ||
| 84A216441P1 | SHIELD | ||
| 41C666570G1 | 2 | PRINTED WIRE BOARD | |
| 17LV66J46 | 2 | RELAY (SEE PB-76012-015) | |
| 41A321261G1 | 1 | MODULE | |
| 41A254891P1 | 1 | TOGGLE SWITCH,3 AMP,250 VOLT | |
| 84A220146G1 | 1 | RESISTOR PANEL | |
| 41A267741P2 | 2 | TOGGLE SWITCH,TWO POSITION,PULLTO UNLOCK | |
| 17FR402A1 | 2 | RESISTORASSEMBLY | |
| 41A296301AMP4 | 16 | RESISTOR,375 OHM,225 WATT | |
| 8815345P1 | 32 | BUSHING,INSULATOR,11/8 IN OD | |
| 41A265399P4 | 12 | CONNECTION STRIP,23/4 INLONG | |
| N22P25010B13 | 2 | BOLT,HEX HD,3/8 IN-16,5/8 IN LONG | |
| 41A296328AKP7 | 13 | CURRENT MODULE SENSOR,AC-DC | |
| 41A278283G2 | 1 | RESISTOR PANEL(17FR102A1) | |
| 2793982G7 | 2 | RESISTOR UNIT,1.03 OHM | |
| 9963853G1 | 2 | CONTACT CLIP ASSEMBLY | |
| 17FH41A1 | 1 | AC DRIVE POWER SUPPLY | |
| 41A259026P2 | 1 | THYRITE(STAMPED 9RV6A7) | |
| N402P47B13 | 12 | WASHER,5/8 IN | |
| N405P47B13 | 12 | LOCKWASHER,5/8 IN | |
| N258P33B13 | 12 | NUT,HEX,5/8 IN-11 | |
| 41A256612P1 | 1 | SHIELD,INSULATION,1/16 IN THK,3 HOLES | |
| 41A256612P2 | 1 | SHIELD,INSULATION,1/16 IN THK,2 HOLES | |
| SEAT SUSPENSION ASSEMBLYXA5816 | ||
| Item Part No Description | Qty | |
| 1 XA4923 SHAFT,BEARING | 4 | |
| 2 XA4920 HOUSING,UPPER | 1 | |
| 3 XA4962 NUT,CENTERLOCK-3/8"-16NC | 10 | |
| 4 XA4932 BRACKET,CABLE | 1 | |
| 5 XA4965 CAPSCREW-1/4”-20NCX5/8" | 2 | |
| 6 XA4952 CAPSCREW-1/4"-20NCX11/2" | 1 | |
| 7 XA4951 CAPSCREW-#6-32NC×1/2" | 7 | |
| 8 XA4931 KNOB | ||
| 9 XA4954 SPRING,COMPRESSION | ||
| 10 XA4946 BALL,BEARING | 1 | |
| 11 XA4950 LOCKNUT-#6-32NC | 1 | |
| 12 XA4961 LOCKNUT-1/4"-20NC | 5 | |
| 13 XA4929 LINK,NARROW TOGGLE | 1 | |
| 14 XA4966 CAPSCREW-3/8"-16NCX1/2" | 1 | |
| 15 XA4943 TUBE,BEARING | 12 | |
| 16 XA4935 SHOULDER BOLT | 2 | |
| 17 XA4957 LOCKWASHER | 2 | |
| 18 )XA4963 FLAT WASHER | 2 | |
| 19) XA4930 RETAINER,BUMPER | 2 | |
| 20 XA4960 CAPSCREW-#8-32NCX11/4" | 2 | |
| 22 XA4939 BUMPER | 2 | |
| 23 XA4959 SCREW-1/4"-20NCX1" | 2 | |
| 24 XA4925 TETHER,BOLT | 2 | |
| 25 XA4924 ARM,SCISSORS | 1 | |
| 26 XA4938 SHOCKABSORBER | 1 | |
| 27 XA4934 CLAMP,COMPRESSOR | 1 | |
| 28 XA4928 LINK,WIDE TOGGLE | ||
| 29 XA4941 SPRING,AIR | 1 | |
| 30 XA4921 HOUSING,LOWER | ||
| 31 XA4958 SCREW-3/8"-16NC | 1 | |
| 32 XA4955 CLIP | 1 | |
| 33 XA4942 BOOT,SUSPENSION | ||
| 34 XA5791 COMPRESSOR | ||
| 35 )XA4956 TUBING,NYLON-5/32"(PRESSURE)(1)(2) | 1 | |
| 36 XA4948 TUBING,CONVOLUTED(VENT) | 1 | |
| 37 XA4933 SHOULDER BOLT | 2 | |
| 38 XA4922 SHOCKABSORBER,ADJUSTABLE | 1 | |
| 39 XA4937 WASHER,SPACER | 4 | |
| 40 XA4940 BEARING | 4 | |
| 41 XA4936 SHAFT,BEARING-LONG 42 XA4926 SHAFT,BEARING-SHORT 43 XA4964 FLAT WASHER |
1 | |
| 1 | ||
| 2 | ||
| 44 XA4927 HARNESS,SEAT COMPRESSOR 45 XA4945 TIE,CABLE(1) |
1 | |
| 1 | ||
| NS XA5074 NOTE:(1)INCLUDED IN XA5074 AIR LINE SERVICE KIT. NS (2)NOT SERVICED SEPARATELY.ORDERXA5074. |
||
