| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| Item | Part No | Description | Qty |
| 0 | EM3840 | SPINDLE,HUB&BRAKE ASSEMBLY | 1 |
| 1 | EL0452 | HOUSING,FRONTWHEEL | 1 |
| 2 | PB7362 | DISC BRAKE ASSEMBLY(SEE INDEX) | 3 |
| 3 | EM3837 | SUPPORT,BRAKE | 1 |
| 4 | WA4682 | CAPSCREW-1"-14NFX141/2" | 18 |
| 5 | WA0364 | FLAT WASHER-1" | 30 |
| 6 | VN7703 | NUT-1"-14NF | 18 |
| 7 | VM8258 | CAPSCREW-1"-8NC×33/4" | 18 |
| 8 | PC0003 | CUP,BEARING(1) | 1 |
| 9 | PC1696 | CONE,BEARING(1) | 1 |
| 10 | EL9508 | SPINDLE | 1 |
| 11 | 562-22-32290 | PIN(1) | 2 |
| 12 | EB1715 | SPACER | 1 |
| 13 | PC2487 | SEAL ASSEMBLY(1) | 1 |
| 14 | VN9143 | CAPSCREW-11/4"-7NCX4" | 56 |
| 15 | TY2149 | FLAT WASHER-11/4" | 62 |
| 16 | TX4848 | DISC | 1 |
| 17 | EM5452 | STUD-1"-14UNSX71/4" | 35 |
| 18 | VM0315 | PLUG,O-RING | 1 |
| 19 | PCO006 | CUP,BEARING(1) | 1 |
| 20 | PC1697 | CONE,BEARING(1) | 1 |
| 21 | SD5211 | PIPE,BUSHING | 1 |
| 22 | PB7454 | GAUGE,SIGHT | 1 |
| 23 | EL9506 | RETAINER,BEARING | 1 |
| 24 | TH6916 | VALVE,CHECK | 1 |
| Item Part No Description | QTY | ||
| 25 | R2491 | PLUG,DRAIN(MAGNETIC) | 1 |
| 26 | TY2148 | FLAT WASHER-1" | 6 |
| 27 | EL9513 | SHIM-.005”(1) | 3 |
| EL9514 | SHIM-.007"(1) | 4 | |
| EL9515 | SHIM- .020"(1) | 5 | |
| 28 | WA4795 | SEAL,O-RING(1) | 1 |
| 29 | C1616 | CAPSCREW-1/2"-13NCX2" | 8 |
| 30 | C1540 | LOCKWASHER-1/2" | 8 |
| 31 | EC3702 | COVER | 1 |
| 32 | WA0362 | FLAT WASHER-3/4"(2) | 4 |
| 33 | TX0807 | ANGLE(2) | 1 |
| 34 | TH7593 | FITTING,ELBOW-90 DEG (2) | 1 |
| 35 | TX0805 | TUBE(2) | 1 |
| 36 | VY8331 | CLAMP | 1 |
| 37 | DC7524 | CAPSCREW-3/8"-16NCX7/8" | 1 |
| 38 | WA0720 | FLATWASHER-3/8" | 3 |
| 39 | C0312 | LOCKWASHER-3/8" | 3 |
| 40 | C1521 | NUT-3/8"-16NC | 1 |
| 41 | TF5190 | FITTING,TUBE CONNECTOR(2) | 1 |
| 42 | TR6102 | SCREW,BLEEDER | 2 |
| 43 | TX0808 | BOSS,BLEEDER REMOTE(2) | 1 |
| 44 | EM6445 | BRACKET | 1 |
| 45 | VN3275 | CAPSCREW-11/4"-7NC×51/2" | 8 |
| 46 | EL0628 | SPACER | 8 |
| 47 | EL0627 | GEAR | 1 |
| 48 | SL5023 | O-RING(1) | 1 |
| Item | Part No | Description | Qty |
| 49 | TC1234 | CAPSCREW-3/8"-16NC×3/4" | 2 |
| 50 | XC1933 | PLATE ASSEMBLY | 1 |
| XB8490 | PLATE | 1 | |
| 58E-93-00610 | DECAL,PRESSURIZED FLUID (SPANISH) | 1 | |
| NS | AK5511 | NOTE:(1)INCLUDED INAK5511 BEARING AND SEAL KIT. |
|
| NS | (2)USED ON TOP BRAKE HEAD ONLY. | ||
| NS | (QUANTITIES SHOWNARE FOR ONE SIDE ONLY.) | ||
| VISOR INSTALLATION | |||
| Item | Part No | Description | Qty |
| 1 | EK2770 | SHEET,FORMED | 2 |
| 2 | PB9829 | SCREW-M6×1.00×16 | 4 |
| 3 | SM0926 | SCREW-M6×1.00 | 10 |
| 4 | PB8658 | SCREW-M6×1.00×30 | 1 |
| 5 | SM5244 | VISOR,LENS | 2 |
| 6 | 31127R1 | CAPSCREW-M6×1.00×12 | 6 |
| 7 | MM0207 | LOCKWASHER-M6 | 6 |
| 8 | 58E-54-03880 | CLOSURE,FRONT | 1 |
