| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| Item | Part No | Description | Qty |
| 0 | EM3840 | SPINDLE,HUB&BRAKE ASSEMBLY | 1 |
| 1 | EL0452 | HOUSING,FRONTWHEEL | 1 |
| 2 | PB7362 | DISC BRAKE ASSEMBLY(SEE INDEX) | 3 |
| 3 | EM3837 | SUPPORT,BRAKE | 1 |
| 4 | WA4682 | CAPSCREW-1"-14NFX141/2" | 18 |
| 5 | WA0364 | FLAT WASHER-1" | 30 |
| 6 | VN7703 | NUT-1"-14NF | 18 |
| 7 | VM8258 | CAPSCREW-1"-8NC×33/4" | 18 |
| 8 | PC0003 | CUP,BEARING(1) | 1 |
| 9 | PC1696 | CONE,BEARING(1) | 1 |
| 10 | EL9508 | SPINDLE | 1 |
| 11 | 562-22-32290 | PIN(1) | 2 |
| 12 | EB1715 | SPACER | 1 |
| 13 | PC2487 | SEAL ASSEMBLY(1) | 1 |
| 14 | VN9143 | CAPSCREW-11/4"-7NCX4" | 56 |
| 15 | TY2149 | FLAT WASHER-11/4" | 62 |
| 16 | TX4848 | DISC | 1 |
| 17 | EM5452 | STUD-1"-14UNSX71/4" | 35 |
| 18 | VM0315 | PLUG,O-RING | 1 |
| 19 | PCO006 | CUP,BEARING(1) | 1 |
| 20 | PC1697 | CONE,BEARING(1) | 1 |
| 21 | SD5211 | PIPE,BUSHING | 1 |
| 22 | PB7454 | GAUGE,SIGHT | 1 |
| 23 | EL9506 | RETAINER,BEARING | 1 |
| 24 | TH6916 | VALVE,CHECK | 1 |
| Item Part No Description | QTY | ||
| 25 | R2491 | PLUG,DRAIN(MAGNETIC) | 1 |
| 26 | TY2148 | FLAT WASHER-1" | 6 |
| 27 | EL9513 | SHIM-.005”(1) | 3 |
| EL9514 | SHIM-.007"(1) | 4 | |
| EL9515 | SHIM- .020"(1) | 5 | |
| 28 | WA4795 | SEAL,O-RING(1) | 1 |
| 29 | C1616 | CAPSCREW-1/2"-13NCX2" | 8 |
| 30 | C1540 | LOCKWASHER-1/2" | 8 |
| 31 | EC3702 | COVER | 1 |
| 32 | WA0362 | FLAT WASHER-3/4"(2) | 4 |
| 33 | TX0807 | ANGLE(2) | 1 |
| 34 | TH7593 | FITTING,ELBOW-90 DEG (2) | 1 |
| 35 | TX0805 | TUBE(2) | 1 |
| 36 | VY8331 | CLAMP | 1 |
| 37 | DC7524 | CAPSCREW-3/8"-16NCX7/8" | 1 |
| 38 | WA0720 | FLATWASHER-3/8" | 3 |
| 39 | C0312 | LOCKWASHER-3/8" | 3 |
| 40 | C1521 | NUT-3/8"-16NC | 1 |
| 41 | TF5190 | FITTING,TUBE CONNECTOR(2) | 1 |
| 42 | TR6102 | SCREW,BLEEDER | 2 |
| 43 | TX0808 | BOSS,BLEEDER REMOTE(2) | 1 |
| 44 | EM6445 | BRACKET | 1 |
| 45 | VN3275 | CAPSCREW-11/4"-7NC×51/2" | 8 |
| 46 | EL0628 | SPACER | 8 |
| 47 | EL0627 | GEAR | 1 |
| 48 | SL5023 | O-RING(1) | 1 |
| Item | Part No | Description | Qty |
| 49 | TC1234 | CAPSCREW-3/8"-16NC×3/4" | 2 |
| 50 | XC1933 | PLATE ASSEMBLY | 1 |
| XB8490 | PLATE | 1 | |
| 58E-93-00610 | DECAL,PRESSURIZED FLUID (SPANISH) | 1 | |
| NS | AK5511 | NOTE:(1)INCLUDED INAK5511 BEARING AND SEAL KIT. |
|
| NS | (2)USED ON TOP BRAKE HEAD ONLY. | ||
| NS | (QUANTITIES SHOWNARE FOR ONE SIDE ONLY.) | ||
| VISOR INSTALLATION | |||
| Item | Part No | Description | Qty |
| 1 | EK2770 | SHEET,FORMED | 2 |
| 2 | PB9829 | SCREW-M6×1.00×16 | 4 |
| 3 | SM0926 | SCREW-M6×1.00 | 10 |
| 4 | PB8658 | SCREW-M6×1.00×30 | 1 |
| 5 | SM5244 | VISOR,LENS | 2 |
| 6 | 31127R1 | CAPSCREW-M6×1.00×12 | 6 |
| 7 | MM0207 | LOCKWASHER-M6 | 6 |
| 8 | 58E-54-03880 | CLOSURE,FRONT | 1 |
|
Item1 2 3 4 5 6 7 8 9 10 11 12 |
Part NoWB2528 58B-93-00470 58B-93-00480 WB2508 WB2517 WA3417 WB3242 WB2764 WB2513 WB2514 WB3347 WB3348 |
Description DECAL, EMERGENCY TOWING PROCEDURE (L.H. SIDE OF FRAME BEHIND ACCUMULATORS) DECAL, MASTER DISCONNECT (BATTERY BOX) DECAL, STARTER DISCONNECT (BATTERY BOX) DECAL, NEGATIVE GROUND (BATTERY BOX) DECAL, LIFTING INSTRUCTIONS (RETARDING GRID BOX) PLATE, HIGH PRESSURE NITROGEN CYLINDER DANGER (FRONT & REAR SUSPENSION CYLINDERS) DECAL, LIFTING INSTRUCTIONS (CONTROL CABINET) DECAL, HIGH PRESSURE WARNING (BRAKE CABINET DOOR) DECAL, LIFTING POINT (TOP OF CAB) DECAL, LIFTING (REAR OF CAB) DECAL, EMERGENCY EXIT (BOTH EMERGENCY LADDERS) DECAL, BATTERY CABLE REMOVAL (BATTERY BOX) |
