A.F.S.E. PANEL A.F.S.E. PANEL COVER PANEL COVER ASSEMBLY COVER ASSEMBLY 2/2 ASSEMBLY 2/2 58B-43-00480 2/2 58B-43-00480
Item Part No
Description
Qty uom
1 58B-43-00500 BASE
1
2 VE3847 CONDENSER
4
3 VE5967 CLAMP
4
4 58B-43-00610 GASKET
4
5 DECAL (1)
1
6 58B-43-00600 WASHER, RETAINING
2
7 VJ6586 CAPSCREW - #10 - 32NF X 3/4"
10
8 VS6662 FLAT WASHER - #10
AS REQUIRED
9 VE4601 LOCKWASHER - #10
AS REQUIRED
10 SF2755 NUT - #10 - 32NF
AS REQUIRED
11 HE5125 FLAT WASHER - #6
4
12 DF4944 LOCKWASHER - #6
4
13 VE5959 NUT
4
14 VS6823 RESISTOR
2
15 VE5976 SCREW - #6 - 40NF X 7/8"
1
16 58B-43-00590 BRACKET
1
17 VE4610 SCREW - #10 - 32NF X 5/8"
4
18 XA5817 MODULE
2
58B-43-00520
RESISTOR
2
58B-43-00530
CAPACITOR
2
58B-43-00540
DIODE
2
58B-43-00550
TRANSFORMER
2
58B-43-00560
BOARD, TERMINAL
2
58B-43-00570
RESISTOR
2
VE6548
CAPACITOR
2
19 VE4597 WASHER - 1/2"
8
20 VE5974 SCREW - #10 - 32NF X 1 1/8"
5
21 VS6820 MODULE
2
22 VS6990
RESISTOR
2
23 VS6996
RESISTOR
2
24 VE2616
DIODE
2
25 VS7210
CAPACITOR
2
26 VS7214
DIODE
2
27 VS6610
TRANSIPAD
2
28 VP9597 SCREW - #6 - 40NF X 5/8"
3
NS NOTE: (1) NOT SERVICED SEPARATELY
