CONTACTOR - CONTACTOR - - - GF GF GF GF & & & & GFR GFR VE1317 GFR VE1317
Item Part No
Description
Qty Page
1 VE1317 CONTACTOR - GF & GFR (SEE INDEX)
1 652
2 VS8925 MAGNET, FRAME
1
3 VS8908 CORE
1
4 VS9207 MACHINE SCREW / LOCKWASHER - #8 - 36NF X 1/2"
1
5 VS9322 FRAME, SPRING BRACKET
1
6 VK0979 CAPSCREW / LOCKWASHER - 3/8" - 16NC X 3/4"
2
7 VM0242 SPRING W/ PLUG
1
8 VE5771 LOCKWASHER - #10 (EXTERNAL TOOTH)
1
9 SF2755 NUT - #10 - 32NF
1
10 VS9034 MACHINE SCREW - #10 - 32NF X 2 7/16"
1
11 BF1890 ARMATURE ASSEMBLY
1
12 R3869 CAPSCREW - 5/16" - 18NC X 5/8"
2
C1538 LOCKWASHER - 5/16"
2
13 VM0275 SHUNT
1
14 VS9172 PIN
1
15 VS9171 CLAMP
2
16 VS9209 MACHINE SCREW / LOCKWASHER - #10 - 32NF X 1/2"
2
17 VS8285 CONTACT ARM
1
18 VE5761 COTTER PIN
1
19 VS9175 SEAT, SPRING
1
20 VM0253 SPRING
1
21 VJ7860 CAPSCREW - 5/16" - 18NC X 1 1/4"
4
22 VE4696 LOCKWASHER - 5/16"
8
23 AK1960 FLAT WASHER - 5/16"
8
24 DC3584 LOCKWASHER - 1/4"
3
25 VE4347 NUT
3
26 VE2250 CAPSCREW - 5/16" - 18NC X 2 1/4"
2
27 VE2249 CAPSCREW - 5/16" - 18NC X 2"
2
28 C1603 CAPSCREW - 3/8" - 16NC X 1 1/4"
1
C0312 LOCKWASHER - 3/8"
1
29 VJ8979 CLAMP
1
30 VJ9150 CAPSCREW - 1/4" - 20NC X 3 1/2"
1
31 VE4604 FLAT WASHER - #8 (NARROW)
1
32 VJ8710 INSULATION FLANGE
2
33 BF1891 CORE FLANGE
2
34 BF1892 CORE
1
35 VS6662 FLAT WASHER - #10
2
36 VJ9158 MACHINE SCREW - #10 - 32NF X 3/8"
2
H2643 LOCKWASHER - #10
2
37 VS6881 FLAT WASHER - 5/16" (BRASS)
2
38 VS7830 SPACER
1
39 VM0217 HORN, ARC CHUTE
1
40 VM0229 HORN, ARCING
1
41 VE7738 BLOCK, SUPPORT
1
42 VS7165 BLOCK
1
43 VS7166 BLOCK
1
44 VS7132 INSULATION
1
45 VE2248 SHIM
1
46 VM0229 HORN, ARCING
1
47 (NOT USED IN THIS APPLICATION)
48 VJ1124 SUPPORT, BLOWOUT COIL
1
49 VE3288 PLATE, LOCKING
1
50 VE0252 WASHER, SPRING
1
51 VE1183 TIP, CONTACT
2
52 VJ0846 ARC CHUTE
