1
WB2511
DECAL, RADIATOR CAP WARNING (TOP OF GRILLE)
1
2
WB2527
DECAL, WELDING CAUTION (BELOW RH LADDER)
1
3
WB3029
CHART, LUBE (BEHIND RH LADDER)
1
4
EM3240
PLATE, EMERGENCY SHUTDOWN
1
5
WB2519
DECAL, CAPACITOR CAUTION (CONTROL CABINET - REAR)
1
6
58E-93-00470
DECAL, HIGH VOLTAGE WARNING (CONTROL CABINET AND BLOWN GRID) 6
7
WB2515
DECAL, INFORMATION DISPLAY (CONTROL CABINET)
1
8
WB2509
DECAL, ACCUMULATOR WARNING (ON ACCUMULATORS INSIDE BRAKE
CABINET)
2
9
WB2526
DECAL, BATTERY DANGER (BATTERY BOX)
1
10
WB2516
DECAL, CAPACITOR CHARGE LIGHT (CONTROL CABINET AND REAR WALL
OF CAB)
3
1
WB3290
DECAL, EMERGENCY TOWING PROCEDURE (LH SIDE OF FRAME BEHIND
ACCUMULATOR)
1
2
WB3505
DECAL, WARNING, STORED ENERGY HAZARD
2
3
WB2517
DECAL, LIFTING INSTRUCTIONS (RETARDING GRID BOX)
4
4
WB3289
DECAL, WARNING (AUTOMATIC LUBRICATION)
1
5
WB2512
DECAL, LIFTING INSTRUCTIONS (CONTROL CABINET)
3
6
WB2764
DECAL, HIGH PRESSURE WARNING (CONTROL CABINET - REAR)
4
7
WB2513
DECAL, LIFTING POINT (TOP OF CAB)
8
8
WB2514
DECAL, LIFTING (REAR OF CAB)
3
9
WB3506
DECAL, BATTERY CABLE REMOVAL
1
Item
Part No
Description
Qty
1
WA3925
DECAL, HYDRAIR II
4
2
WB2508
DECAL, NEGATIVE GROUND (BATTERY CONTROL BOX & RH FRONT
BUMPER) (SPANISH)
2
3
WB3472
PLATE, STARTER DISCONNECT (SPANISH)
1
4
WB3506
DECAL, BATTERY CABLE REMOVAL (BATTERY BOX)
1
5
WB3471
PLATE, MASTER DISCONNECT (SPANISH)
1
6
WB3347
DECAL, EMERGENCY EGRESS (VERTICAL LADDER)
2
7
58E-98-10010
DECAL, GRADE SPEED CHART (SPANISH)
1
8
09845-00480
PLATE, SAFETY (OVERHEAD DASH)
1
9
WB3897
DECAL, DANGER HIGH VOLTAGE (INSIDE CONTROL CABINET)
1
Item
Part No
Description
Qty
1
WB3355
DECAL, 830E (BODY FRONT)
1
2
09690-F1000
DECAL, KOMATSU (GRILLE)
1
3
09690-P0710
DECAL, KOMATSU (DOOR)
1
4
WB3353
DECAL, 830E (LH BODY)
1
WB3354
DECAL, 830E (RH BODY)
1
5
09690-P1800
DECAL, KOMATSU (BODY)
3
6
EM8176
PLATE, MOUNTING
1
7
TC1234
CAPSCREW - 3/8" - 16NC X 3/4"
4
8
TC1231
LOCKWASHER - 3/8"
4
Item
Part No
Description
Qty
1
58E-80-02420 GRILLE
1
2
EM9248
HOUSING, HEADLIGHT
2
3
58E-80-02230 COVER, SURGE TANK
1
4
TC1234
CAPSCREW - 3/8" - 16NC X 3/4"
8
5
TC1231
LOCKWASHER - 3/8"
8
6
TR1376
CAPSCREW - 1/2" - 13NC X 1 1/4" 45
7
TR5445
LOCKWASHER - 1/2"
45
8
TR6008
FLAT WASHER - 1/2"
45
9
VN6450
CAPSCREW - 3/8" - 16NC X 7/8"
19
10
C1547
FLAT WASHER - 3/8"
19
11
XC2216
DAM, AIR
1
12
TY7538
CLIP
22
13
WA3364
LOCK SCREW
22
14
EL5323
GRILLE, BOTTOM
2
15
EJ4576
GRILLE, TOP
2
16
PB6877
NUT, LEVER
1
17
TR6008
FLAT WASHER - 1/2"
2
18
EF8143
COVER
1
19
DF3500
LOCKNUT - 1/2" - 13NC
1
20
PB6842
HOOK, RUBBER
2
21
C1639
CAPSCREW - 5/16" - 18NC X 2"
2
22
VN9951
LOCKNUT - 5/16" - 18NC
2
23
MM0604
CAPSCREW - M10 X 1.50 X 20
8
24
MM0471
LOCKWASHER - M10
8
25
MM0461
FLAT WASHER - M10
8
26
TY7535
DAM, AIR
1
27
XC2215
DAM, AIR
1
FRAME & UPRIGHTS
Item
Part No
Description
Qty
1
FRAME, MAIN (1)
1
2
UPRIGHT - RH (1)
1
3
UPRIGHT - LH (1)
1
4
VN9188
CAPSCREW - 5/8" - 11NC X 6 1/2"
8
5
C1525
NUT - 5/8" - 11NC
8
6
ED6340
SUPPORT, DECK - RH
1
7
TUBE, ROPS (1)
1
8
ED6863
PLATE, MOUNT - LEFT INNER
1
9
C1667
CAPSCREW - 1" - 8NC X 2 1/2"
16
10
WA0364
FLAT WASHER - 1"
16
11
MM0109
CAPSCREW - M20 X 2.50 X 90
8
12
MM0707
FLAT WASHER - M20
8
13
ED6335
SUPPORT, DECK - LH
1
14
ED6857
PLATE - RH
1
15
ED6856
PLATE - LH
1
16
ED6858
BACKER
4
17
ED6862
PLATE, MOUNT - LEFT OUTER
1
18
EK9278
SUPPORT
1
19
ED6872
BACKER - LH
2
20
ED6873
BACKER - RH
2
21
ED6859
PLATE, MOUNT - RIGHT OUTER
1
22
ED6860
PLATE, MOUNT - RIGHT INNER
1
NS
NOTE: NS = NOT SHOWN
NS
58E-00-00400 KIT, TOW BUMPER (2)
1
NS
NOTE: (1) ORDER FROM FACTORY.
NS
(2) OPTIONAL WELD-ON COMPONENT.
Item Part No
Description
Qty
1
TG5720 CAPSCREW - 3/8" - 16NC X 1" 6
2
TC1231
LOCKWASHER - 3/8"
6
3
WA4726 FLAT WASHER - 3/8"
6
4
XB1734
COVER, ACCESS
1
Item
Part No
Description
Qty
1
58E-54-04760 DECK, RH
1
2
EJ2443
BRACKET
1
3
D104556
BUMPER, RADIATOR STABILIZER 1
4
MM0031
CAPSCREW - M20 X 2.50 X 45
4
5
MM0707
FLAT WASHER - M20
4
6
EC7589
PLATE
1
7
TR6643
NUT - 1/2" - 13NC
1
8
VC7836
FLAT WASHER - 1/2"
1
9
MM0697
LOCKNUT - M20 X 2.50
8
10
EG9144
SPACER
8
11
EC7594
FLAT WASHER - 3/4"
8
12
MM0128
CAPSCREW - M20 X 2.50 X 110
8
