| NC REF QTY PART NO. DESCRIPTION FROM TO |
| 001 001 15255404 ENGINE ASSY-M11-C350 |
| 002 001 15266844 .FILTER-LUBE OIL |
| 003 001 15266845 .FILTER WF-15DCA4 |
| 004 002 15266846 .FILTER-FUEL |
| 005 001 15269115 .BELT ALTERNATOR |
| 006 001 15303616 .BELT-FAN DRIVE |
| 007 004 15235607 WASHER |
| 008 004 00106269 WASHER |
| 009 004 00274098 LOCKNUT |
| 010 008 00271560 BOLT |
| 011 008 00103331 LOCKWASHER |
| 012 001 15258665 ENGINE FAN |
| 013 ASR 15258531 HOSE BULK |
| 014 002 15248752 CLAMP |
| 015 001 15258509 BENT PLATE |
| 016 001 09131853 CLIP |
| 017 001 00179837 BOLT |
| 018 001 00102635 NUT T50 |
| 019 001 00108580 LOCKWASHER |
| 020 001 00106263 WASHER T50 |
| 021 001 00179816 BOLT |
| 022 001 00102634 NUT |
| 023 001 00446362 WASHER |
| 024 001 15257182 BRACKET-FRONT MTG |
| 025 002 15257254 BRACKET-ENG MTG REAR |
| 026 002 00271611 BOLT |
| 027 006 09430211 BOLT |
| 028 001 15253858 FLANGE COUPLING |
| 029 001 15253832 DAMPER |
| 030 006 09409090 BOLT |
| 031 012 09409027 BOLT |
| 032 001 15300234 PLATE ASSY |
| 033 001 15303351 COVER PLATE |
| 034 002 15303584 BOLT,HEX HD M10 X 1.50 |
| 035 002 09060202 WASHER-HARDENED |
| 036 004 15311297 ISOLATOR |
| 037 004 15251433 BOLT |
| NC REF QTY PART NO. DESCRIPTION FROM TO |
| 001 ASR 09113457 LOCKWIRE |
| 002 028 15019509 BOLT DRILL HEAD 0.50 |
| 003 002 09008525 PLUG-MAGNETIC |
| 004 002 00273469 PLUG |
| 005 002 15009631 CARRIER-PLANETARY |
| 006 008 15334788 PINION-PLANETARY |
| 007 003 15233274 RETAINER |
| 008 008 15233267 PIN-PLANETARY |
| 009 012 15232937 PLATE-THRUST |
| 010 012 09074668 SPACER |
| 011 016 15238327 BEARING |
| 012 008 15238323 SPACER-BEARING |
| 013 012 00454910 BOLT |
| 014 006 15233266 PIN-PLANETARY |
| 015 024 15019502 BOLT DRILL HEAD 0.38 |
| 016 006 09074670 SPACER |
| A 017 006 15334787 PLANET PINION-FIRST |
| 018 002 15334786 PINION-SUN |
| 019 002 15019492 PLATE-RETAINER |
| A 020 002 15337703 CARRIER-PLANTRY M/CD |
| 021 016 15238322 SPACER-THRUST |
| 022 002 15233271 COVER-PLANETARY |
| 023 002 15019519 WASHER-THRUST |
| A 024 002 15334785 SUN PINION-FIRST |
| A 025 002 15245290 WASHER-THRUST |
| 026 ASR 09125576 O RING-BULK |
| 027 002 15228596 RING-GEAR |
| 028 002 15233268 COVER CARRIER |
| 029 056 09430309 BOLT |
| 030 056 09250715 WASHER-HARDENED |
| 031 002 09141863 O RING |
| 032 008 15233269 RETAINER |
| 033 012 15019494 RETAINER |
| 034 002 15334790 RING-GEAR |
| 035 048 15019502 BOLT DRILL HEAD 0.38 |
| 036 001 09413420 RING-SNAP |
| 037 002 15337702 CARRIER-RING GEAR |
| 038 036 09433576 NUT |
| 039 016 15246062 WASHER-THRUST |
| 040 012 15015363 BEARING |
| 041 006 00139230 SCREW |
| NOTES: |
| A FOR STANDARD 13.75:1 GEAR REDUCTION |
| 15337187 FOR COMPLETE PLANETARY ASSEMBLY. |
| THROTTLE SENSOR AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15251067 | SENSOR-THROTTLE |
| FRONT DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300850 | DRIVELINE-FRONT |
| 2 | 15272863 | BOLT |
| 3 | 15272865 | UNIVERSAL JOINT |
| 4 | 15336537 | DRIVELINE-FRONT |
| REAR DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15258114 | DRIVELING 12.5 C-DEAR |
| 2 | 15271476 | UNIVERSAL JOINT |
| 3 | 15271477 | BOLT/NUT SET |
| 4 | 15272031 | BOLT |
| WHEEL,RIM AND TYPE-FRONT | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9262036 | GASKET |
| 2 | 9062605 | SEAL |
| 3 | 9016245 | RING-SNAP |
| 4 | 9062643 | WASHER |
| 5 | 9418488 | CONE |
| 6 | 456513 | CUP |
| 7 | 15236015 | WHEEL-FRONT |
| 8 | 9253468 | STUD |
| 9 | 9062983 | CLAMP |
| 10 | 9209490 | O RING |
| 11 | 9433576 | NUT |
| 12 | 9063834 | FLANGE |
| 13 | 15017037 | BASE |
| 14 | 9074982 | BAND-BEAD SEAT |
| 15 | 9074983 | LOCKRING |
| 16 | 9427249 | CUP-BEARING |
| 17 | 9428203 | CONE-BEARING |
| 18 | 9019828 | SHIM PACK |
| 19 | 9019600 | PLATE |
| 20 | 9256717 | BOLT |
| 21 | 9019601 | CAP |
| 22 | 454989 | BOLT |
| 23 | 103329 | LOCKWASHER |
| 24 | 9113457 | LOCKWIRE |
| 25 | 15302218 | SPINDLE ASSEMBLY-LEF |
| 26 | 9062561 | BUSHING |
