| NC REF QTY PART NO. DESCRIPTION FROM TO |
| 001 001 15255404 ENGINE ASSY-M11-C350 |
| 002 001 15266844 .FILTER-LUBE OIL |
| 003 001 15266845 .FILTER WF-15DCA4 |
| 004 002 15266846 .FILTER-FUEL |
| 005 001 15269115 .BELT ALTERNATOR |
| 006 001 15303616 .BELT-FAN DRIVE |
| 007 004 15235607 WASHER |
| 008 004 00106269 WASHER |
| 009 004 00274098 LOCKNUT |
| 010 008 00271560 BOLT |
| 011 008 00103331 LOCKWASHER |
| 012 001 15258665 ENGINE FAN |
| 013 ASR 15258531 HOSE BULK |
| 014 002 15248752 CLAMP |
| 015 001 15258509 BENT PLATE |
| 016 001 09131853 CLIP |
| 017 001 00179837 BOLT |
| 018 001 00102635 NUT T50 |
| 019 001 00108580 LOCKWASHER |
| 020 001 00106263 WASHER T50 |
| 021 001 00179816 BOLT |
| 022 001 00102634 NUT |
| 023 001 00446362 WASHER |
| 024 001 15257182 BRACKET-FRONT MTG |
| 025 002 15257254 BRACKET-ENG MTG REAR |
| 026 002 00271611 BOLT |
| 027 006 09430211 BOLT |
| 028 001 15253858 FLANGE COUPLING |
| 029 001 15253832 DAMPER |
| 030 006 09409090 BOLT |
| 031 012 09409027 BOLT |
| 032 001 15300234 PLATE ASSY |
| 033 001 15303351 COVER PLATE |
| 034 002 15303584 BOLT,HEX HD M10 X 1.50 |
| 035 002 09060202 WASHER-HARDENED |
| 036 004 15311297 ISOLATOR |
| 037 004 15251433 BOLT |
| NC REF QTY PART NO. DESCRIPTION FROM TO |
| 001 ASR 09113457 LOCKWIRE |
| 002 028 15019509 BOLT DRILL HEAD 0.50 |
| 003 002 09008525 PLUG-MAGNETIC |
| 004 002 00273469 PLUG |
| 005 002 15009631 CARRIER-PLANETARY |
| 006 008 15334788 PINION-PLANETARY |
| 007 003 15233274 RETAINER |
| 008 008 15233267 PIN-PLANETARY |
| 009 012 15232937 PLATE-THRUST |
| 010 012 09074668 SPACER |
| 011 016 15238327 BEARING |
| 012 008 15238323 SPACER-BEARING |
| 013 012 00454910 BOLT |
| 014 006 15233266 PIN-PLANETARY |
| 015 024 15019502 BOLT DRILL HEAD 0.38 |
| 016 006 09074670 SPACER |
| A 017 006 15334787 PLANET PINION-FIRST |
| 018 002 15334786 PINION-SUN |
| 019 002 15019492 PLATE-RETAINER |
| A 020 002 15337703 CARRIER-PLANTRY M/CD |
| 021 016 15238322 SPACER-THRUST |
| 022 002 15233271 COVER-PLANETARY |
| 023 002 15019519 WASHER-THRUST |
| A 024 002 15334785 SUN PINION-FIRST |
| A 025 002 15245290 WASHER-THRUST |
| 026 ASR 09125576 O RING-BULK |
| 027 002 15228596 RING-GEAR |
| 028 002 15233268 COVER CARRIER |
| 029 056 09430309 BOLT |
| 030 056 09250715 WASHER-HARDENED |
| 031 002 09141863 O RING |
| 032 008 15233269 RETAINER |
| 033 012 15019494 RETAINER |
| 034 002 15334790 RING-GEAR |
| 035 048 15019502 BOLT DRILL HEAD 0.38 |
| 036 001 09413420 RING-SNAP |
| 037 002 15337702 CARRIER-RING GEAR |
| 038 036 09433576 NUT |
| 039 016 15246062 WASHER-THRUST |
| 040 012 15015363 BEARING |
| 041 006 00139230 SCREW |
| NOTES: |
| A FOR STANDARD 13.75:1 GEAR REDUCTION |
| 15337187 FOR COMPLETE PLANETARY ASSEMBLY. |
| 001 002 00139230 SCREW |
| 002 004 00223441 BOLT |
| 003 001 15007603 PLATE |
| 004 001 15315244 YOKE-ASSY |
| 005 001 15007621 .SLEEVE |
| 006 001 15007642 DIFFERENTIAL ASSY |
| 007 004 09114897 .SCREW |
| 008 003 00139191 .SCREW |
| 009 001 15007635 .RETAINER |
| 010 014 00271567 .BOLT |
| 011 ASR 15007647 .SHIM (0.010 IN) |
| 011 ASR 15007646 .SHIM (0.003 IN) |
| 012 001 15000417 .SEAL |
| 013 001 15235836 .CUP |
| 014 001 15235835 .CONE |
| 015 001 15019463 .GEAR-SET |
| 016 001 15235837 .CUP |
| 017 001 15235838 .CONE |
| 018 ASR 15007650 .SHIM (0.010 IN) |
| 018 ASR 15007649 .SHIM (0.003 IN) |
| 019 001 15007634 .HOUSING |
| 020 004 09192618 ..DOWEL-BUSHING |
| 021 004 09216692 ..BOLT |
| A 022 ASR 09113457 .LOCKWIRE |
| 023 004 09170517 .BOLT |
| 024 002 09245142 .LOCK |
| 025 002 09245234 .BEARING-ADJUSTER |
| B 026 024 09419496 .NUT |
| 027 NOT USED |
| 028 024 00223775 .BOLT |
| 029 002 09427249 .CUP-BEARING |
| 030 002 09428203 .CONE-BEARING |
| 031 001 15019476 .CASE |
| 032 008 09430296 ..BOLT |
| 033 NOT USED |
| 034 NOT USED |
| 035 002 15334185 .WASHER |
| 036 004 15334410 .PIN-DOWEL |
| 037 002 09272352 .GEAR |
| 038 001 09272346 .SPIDER |
| 039 004 09272386 .PINION |
| 040 NOT USED |
| 041 004 00137393 .BEARING |
| 042 001 09141860 O RING |
| NOTES: |
| A USE 18 GAUGE SOFT ANNEALED WIRE OR EQUIVILANT |
| B THE FOLLOWING REF NUMBERS ARE OMITTED FROM THIS SECTION |
| 27,33,34 & 40 |
| 043 002 15303353 STUD |
| 044 022 09250715 WASHER - HARDENED |
| 045 002 09419493 LOCKNUT |
| 046 020 00223453 BOLT |
| 047 ASR 15305445 LOCTITE 7063 |
| 048 ASR 15333986 LOCTITE 518 |
