Terex earthmoving equipment parts
MAIN PRESSURE REGULATOR VALVE
NC NO. QTY PART NO. DESCRIPTION
001 007 09409045 BOLT
002 007 09422848 WASHER
003 001 29525040 BODY ASSY
004 001 09417797 ·SCREW
005 001 29500034 ·PLUG
006 001 29525039 ·BODY-MAIN PRESS REG
007 001 06770075 ·VALVE
008 001 06758907 ·STOP
009 001 06758508 ·SPRING
010 ASR 06769783 ·SHIM
010 ASR 06769264 ·SHIM
011 001 06776680 ·PLUG
012 001 06760112 ·GASKET
013 001 06758461 ·PLUG
014 001 23016548 GASKET
001 001 06880860 GASKET
002 005 09409231 BOLT
003 003 09422847 WASHER
004 003 09409226 BOLT
005 001 29536480 LOCKUP VALVE
006 001 06771005 ·RING
007 001 06758543 ·PLUG
008 001 06838520 ·SPRING
009 001 06770023 ·VALVE ROD
010 001 00273921 ·PIN
011 001 29527366 ·BODY
012 001 29500034 ·PLUG ASSY
013 002 29525044 ·PLUG ASSY
014 001 23045876 ·GASKET
015 001 23019734 ·SOLENOID 12V
016 002 00103339 ·WASHER
017 001 00186647 ·BOLT
018 001 29536509 ·HARNESS ASSY
019 001 23046474 ·CONNECTION SOCKET
020 001 23016455 ·SEAL RING
021 002 12052410 ·TERMINAL
022 001 12059716 ·CONNECTION BODY
023 001 12047664 ·LOCK
024 001 12047767 ·TERMINAL
NC NO. QTY PART NO. DESCRIPTION
025 001 12047662 ·CONNECTION BODY
026 001 12129691 ·SENSOR
027 001 NSS ·COVER SOLEENOID
028 002 00103339 ·WASHER
029 002 00454815 ·BOLT
