051 001 15036176 .BOLT
052 001 15036006 .WASHER-SPRING
053 001 20011727 .BRACKET-INSTRUMENT
DASH
054 002 15036176 .BOLT
055 002 15036006 .WASHER-SPRING
056 002 15037124 .WASHER-PLAIN
057 002 15036288 .BOLT
058 002 15036083 .WASHER
059 002 15036284 .BOLT
060 002 15036074 .WASHER-SPRING
| 5-5 |
CAB ASSEMBLY 017 01 6171 |
| FROM SERIAL NO. T6171903 |
| NC REF QTY PART NO. DESCRIPTION NC REF QTY PART NO. |
| DESCRIPTION |
061 002 15036344 .WASHER
062 001 20011444 .RUBBER RETAINER
063 001 20011734 .COVER
PLATE-RECEIVER
064 002 15270901 .SWITCH FRAME
065 001 20011726 .INSTRUMENT PANEL
066 002 15036005 .SCREW
067 003 20011059 .AIR OUTLET
068 002 15036280 .SCREW
| 069 004 15036006 .WASHER-SPRING |
091 001 20011743 .FRONT RIGHT INTERIOR |
| 070 004 15036177 .NUT |
LINING |
| 071 004 15036279 .SCREW |
092 001 20011746 .REAR LEFT INTERIOR |
| 072 004 15036068 .WASHER-SPRING |
LINING |
| 073 004 15036067 .NUT |
093 001 20011740 .REAR RIGHT INTERIOR |
| 074 ASR 20011061 .WIND PIPE |
LINING |
| 075 010 20011062 .CLIP-TUBE |
094 001 20011744 .INTERIOR |
| 076 001 20011728 .AIR INLET ASSY |
LINING-TOP |
| 077 003 15036280 .BOLT |
095 ASR 20011752 .PLASTIC EXPANSION |
| 078 003 15036074 .WASHER-SPRING |
SCREW |
| 079 002 15270908 .BLOCK |
096 001 20011750 .REAR UPPER INTERIOR |
| 080 001 20011729 .LOCK |
LINING |
| 081 002 15036006 .SCREW |
097 001 20011751 .REAR LOWER INTERIOR |
082 001 15270794 .ELEMENT
083 001 15270796 .ELEMENT CASING
084 007 15036284 .BOLT
085 007 15036344 .WASHER-PLAIN
086 007 15036074 .WASHER-SPRING
087 007 15036009 .NUT
088 ASR 15270767 .WIND PIPE
089 002 15270768 .CLIP-TUBE
090 001 20011745 .FRONT LEFT INTERIOR
LINING
LINING
