| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| RETARDER GRID GROUP | |||||||
| Item | Part No | Description | Qty uom Ref | ||||
| 25 | XA5829 | RESISTOR | 2 | ||||
| 26 | 58E-06-00850 | RESISTOR | 2 | ||||
| 27 | XA4147 | SUPPORT,CLEAT | 2 | ||||
| 28 | XA3342 | CLEAT | 3 | ||||
| 29 | XA4548 | BUS,BAR | 1 | ||||
| 30 | VX0421 | CAPSCREW-1/2"-13NC×31/4"1 | |||||
| 31 | GE0044 | WASHER | ASREQUIRED | ||||
| 32 | VC1390 | LOCKWASHER-5/8" | ASREQUIRED | ||||
| 33 | GE0045 | NUT-5/8"-11NC | AS REQUIRED | ||||
| 34 | 58E-06-00860 | RESISTOR GRID | |||||
| 35 | 58E-06-00870 | RESISTOR GRID | |||||
| 36 | GE0038 | SPACER | |||||
| 37 | XA2741 | NUT-5/8"-11NC | ASREQUIRED | ||||
| 38 | GE0042 | WASHER-5/8" | ASREQUIRED | ||||
| 39 | GE0023 | INSULATOR | 28 | ||||
| RETARDER GRID GROUP | |||||||
| RETARDING GRID ASSEMBLY 21758E-06-00921 | |||||||
| Item Part No Description | |||||||
| 1 XA4336 | BUS BAR 2 | ||||||
| 2 GE0030 | BUS,BAR 3 | ||||||
| 3 TC1234 | CAPSCREW-3/8"-16NCX 3/4"2 | ||||||
| 4 VE4687 | LOCKWASHER-3/8" | AS REQUIRED | |||||
| AS REQUIRED | |||||||
| 6 PB8167 | CAPSCREW-1/2"-13NCX61/2" | AS REQUIRED | |||||
| ASREQUIRED | |||||||
| 8 VE4699 | LOCKWASHER-1/2" | AS REQUIRED | |||||
| 9 VE4698 | NUT-1/2"-13NC | AS REQUIRED | |||||
| 10 GE0479 | INSULATOR ASSEMBLY | 2 | |||||
| 11 XA4146 | MOTOR.BLOWER(SEE | INDEX)1 | 64335 | ||||
| 12 VE4999 | CAPSCREW-12"-13NCX2" | AS REQUIRED | |||||
| 13 GE0041 | WASHER | ASREQUIRED | |||||
| BUS,BAR | 2 | ||||||
| 15 GE1815 | DIFFUSER ASSEMBLY | ||||||
| GE0019 | GASKET | ||||||
| GE0020 | GASKET | ||||||
| VJ2672 | CEMENT(1 QUART) | AS REQUIRED | |||||
| NUT-5/16"-18NC | AS REQUIRED | ||||||
| 17 VE4696 | LOCKWASHER-5/16" | AS REQUIRED | |||||
| 18 VE4648 | FLAT WASHER-5/16" | AS REQUIRED | |||||
| 19 GE0029 | TUBE | ||||||
| 21 58E-06-03780 | FRAME ASSEMBLY | 2 | |||||
| 22 XA5827 | RESISTOR GRID | 3 | |||||
| 23 GE0021 | COLLAR ASSEMBLY | ||||||
| 24 GE1815 | DIFFUSER ASSEMBLY | ||||||
| GE0020 | |||||||
| CEMENT(1 QUART) | AS REQUIRED | ||||||
| RETARDER GRID GROUP | |||||||
| RETARDING GRID ASSEMBLY 1/758E-06-00921 | |||||||
| Item | Part No | Description | Qty | uom | Ref | ||
| 1 | XA4146 | MOTOR,BLOWER(SEE INDEX) | 1 | 64335 | |||
| 2 | 58E-06-03780 | FRAME ASSEMBLY | 4 | ||||
| 3 | 58E-06-00850 | RESISTOR | 2 | ||||
| 4 | XA5829 | RESISTOR | 2 | ||||
| 5 | GE0021 | COLLAR ASSEMBLY | 2 | ||||
| 6 | GE1815 | DIFFUSER ASSEMBLY | 2 | ||||
| GE0019 | GASKET | 1 | |||||
| GE0020 | GASKET | 1 | |||||
| VJ2672 | CEMENT(1 QUART) | AS REQUIRED | |||||
| 7 | XA5827 | RESISTOR GRID | 3 | ||||
| 8 | XA4523 | RETARDER HOUSING WITH COVERS | 1 | ||||
| 9 | XA4160 | DIFFUSER ASSEMBLY | 2 | ||||
| GE0019 | GASKET | 1 | |||||
| GE0020 | GASKET | 1 | |||||
| VJ2672 | CEMENT(1QUART) | AS REQUIRED | |||||
| RETARDER GRID GROUP | |||||||
| RETARDING GRID INSTALLATION 2/2 | |||||||
| Item | Part No | Description | Qty | ||||
| 1 | EL3714 | MOUNT | 1 | ||||
| 2 | VC8762 | CAPSCREW-3/8"-16NC×11/2" | 2 | ||||
| 3 | TC1231 | LOCKWASHER-3/8" | 2 | ||||
| 4 | TR4436 | FLAT WASHER-3/8" | 2 | ||||
| 5 | TN2590 | SPACER,HOSE | 6 | ||||
| 6 | EH1785 | CLEAT,CABLE | 6 | ||||
| 7 | TG5845 | STUD,THREADED-5/8”-11NC | 2 | ||||
| 8 | TR9082 | FLAT WASHER-5/8" | 3 | ||||
| 9 | VC1390 | LOCKWASHER-5/8" | 3 | ||||
| 10 | TV1749 | NUT-5/8"-11NC | 3 | ||||
| 11 | VN6188 | STUD-5/8"-11NCX71/2" | 1 | ||||
| 12 | VA0609 | SPACER | 2 | ||||
| 13 | ED8936 | CLEAT,CABLE | 4 | ||||
| RETARDER GRID GROUP | |||||||
| RETARDING GRID INSTALLATION Y₂ | |||||||
| Item | Part No | Description | Qty | Ref | |||
| 1 | 58E-06-00921 | GRID,RETARDING(SEE | INDEX)1 | 64341 | |||
| 2 | MM0167 | CAPSCREW-M24X3.00X | 180 | 8 | |||
| 3 | 01643-32460 | FLAT WASHER-M24 | 16 | ||||
| 4 | MM0476 | LOCKWASHER-M24 | 8 | ||||
| 5 | MM0183 | NUT-M24×3.00 | 8 | ||||
| ALTERNATOR GROUP | |||||||
| ALTERNATOR-STATOR ASSEMBLY XA3159 | |||||||
| Item | Part No | Description | Qty | ||||
| 1 | XA3160 | STATOR FRAME &CORE ASSEMBLY | 1 | ||||
| 2 | GE1167 | STATOR REWIND KIT | 1 | ||||
| 3 | (NOT USED IN THIS APPLICATION) | ||||||
| 4 | VE1887 | STRAP,CONNECTION | 1 | ||||
| 5 | VE4342 | BRACKET,INSULATED | 7 | ||||
| 6 | VE2753 | BRACKET | 7 | ||||
| 7 | VE4542 | CAPSCREW-1/2"-13NCX1" | 28 | ||||
| 8 | VE5185 | FLAT WASHER-1/2" | 28 | ||||
| ALTERNATOR GROUP | |||||||
| ALTERNATOR-ROTOR ASSEMBLY 58E-06-03060 | |||||||
| Item | Part No | Description | Qty uom | ||||
| 1 | VJ1063 | STRAP,CONNECTION | 7 | ||||
| 2 | BF1480 | COLLECTOR RING ASSEMBLY | 1 | ||||
| 3 | VE4643 | CLAMP,SUPPORT | 4 | ||||
| 4 | BF4833 | STRIP,BRAZING | 16 | ||||
| 5 | 58E-06-03070 | COIL,ROTOR | 8 | ||||
| 6 | VE7006 | CORE,ROTOR | 1 | ||||
| 7 | BF3105 | RING,TIE | 1 | ||||
| 8 | BF1007 | TAPE,GLASS | AS REQUIRED | ||||
| 9 | VE1001 | STRIP,SLIPPER | 32 | ||||
| 10 | GE1084 | SHAFT,ROTOR | 1 | ||||
| 11 | VJ1069 | WEDGE | 8 | ||||
| 12 | VJ1068 | WEDGE | 8 | ||||
| (ALSO SEE FIGURE 64409 FOR BALANCE OF | |||||||
| ROTOR ASSEMBLY COMPONENTPARTS.) | |||||||
