| 5GE776Wheel Motor | |||
| Item | GE# | Description | QTY |
| 1 | 84E901933G1 | Frame | 1 |
| 2 | 84C620980P1 | shaft | 3 |
| 3 | 84D730317P1 | Torque tube | 1 |
| 4 | 84D730172P1 | 聽 | 1 |
| 5 | 41D735184G1 | Hub-wheel | 1 |
| 6 | 8864961P12 | Bearing-roller | 3 |
| 7 | 8864951P206 | Bearing-roller | 3 |
| 8 | 41A239885P1 | sleeve | 3 |
| 9 | 41C635889G1 | Cap-bearing | 3 |
| 10 | 8864959P15 | Nut-retaining | 3 |
| 11 | 8864959P115 | Lockwasher | 3 |
| 12 | 41A330517P1 | Collar | 3 |
| 13 | 41C635891P3 | Cap-bearing | 3 |
| 14 | 8864953P119 | Bearing-roller | 1 |
| 15 | 8864953P120 | Bearing-roller | 1 |
| 16 | 41C636477P2 | Seal ring | 1 |
| 17 | 41B537454P1 | Ring | 1 |
| 18 | 41A238995P2 | Seal-oil | 2 |
| 19 | 41A238997P2 | Band-wear | 3 |
| 20 | 41B537563P1 | Cap-bearing | 1 |
| 21 | 41C635893P1 | Ring-thrust | 1 |
| 22 | 41B535930G1 | Set of shims | 1 |
| 23 | 41B535930P1 | Shim | 20 |
| 24 | 41B535930P2 | Shim | 16 |
| 25 | 41B535930P3 | Shim | 20 |
| 26 | 41B535930P5 | Shim | 5 |
| 27 | 41B535930P6 | Shim | 4 |
| 28 | 41B535930P7 | Shim | 5 |
| 29 | 41C635863G1 | Seal housing | 1 |
| 30 | 41C636652P2 | Seal ring | 1 |
| 31 | 41C636651P1 | Flinger | 1 |
| 32 | 41A239857P1 | Clamp | 36 |
| 33 | N22P29020B13 | Capscrew | 36 |
| 34 | 2703900P1 | Washer | 144 |
| 35 | 41A238994P1 | Seal-oil | 1 |
| 36 | 41A238996P1 | Packing-felt | 1 |
| 37 | 41A238997P1 | Band-wear | 1 |
| 38 | N5700P21 | Pipe plug | 16 |
| 39 | 41A330184P2 | O-ring | 1 |
| 40 | 41A232900P1 | Pin-torque tube | 1 |
| 41 | 499A910AAP4 | Clamp-hose | 4 |
| 42 | 41B538753P1 | Coupling-oil return | 2 |
| 43 | 41A238941P2 | Ring | 3 |
| 44 | 84D730217G1 | Planet gear cover | 1 |
| 45 | 84A204762P1 | Oil hose | 2 |
| 46 | 84A204762P2 | Hose | 1 |
| 47 | 41A235215P1 | Clamp,hose worm | 6 |
| 48 | 84D730829G1 | Brake line assembly | 1 |
| 49 | 41B538253P1 | Filler cap | 1 |
| 50 | 41A235893P1 | Plug | 2 |
| 51 | N5700P81 | Plug,Pipe | 3 |
| 52 | 41A232942G1 | Plug,magnetic | 1 |
| 53 | 499A904CEP4 | Cap,pipe | 1 |
| 54 | 41C633216P4 | Strap-terminal connection | 3 |
| 55 | 41B537912G | Insulator with stud | 1 |
| 56 | N258P25B13 | nut | 6 |
| 57 | N402P43B13 | Flatwasher | 6 |
| 58 | N405P43B13 | Lockwasher | 6 |
| 59 | 41A235717P2 | Bolt-special | 55 |
| 60 | 41B538385P42 | Capscrew | 45 |
| 61 | 41B537660P21 | Flatwasher | 45 |
| 62 | N22P35040B13 | Capscrew | 24 |
| 63 | 41B537660P14 | Flatwasher | 24 |
