Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| CAB GROUP | ||||
| AIR CONDITIONING PIPING | ||||
| Item | Part No | Description | Qty | |
| 1 | WA1731 | O-RING | 3 | |
| 2 | HA7567 | HOSE | 1 | |
| 3 | WA1733 | O-RING | 1 | |
| 4 | 58E-60-00000 | HOSE | 1 | |
| 5 | WB1304 | CLAMP,CUSHION-9/16" | 12 | |
| 6 | MM0178 | NUT-M10×1.50 | 11 | |
| 7 | MM0471 | LOCKWASHER-M10 | 11 | |
| 8 | MM0461 | FLAT WASHER-M10 | 11 | |
| 9 | WB3093 | CLAMP,CUSHIONED-1" | 11 | |
| 10 | EM1398 | SPACER | 5 | |
| 11 | WB1027 | O-RING | 4 | |
| 12 | 58E-60-00010 | HOSE | 1 | |
| 13 | 20D-09-11130 | CLAMP | 2 | |
| 14 | PC1830 | ACCUMULATOR | ||
| XA4444 | CAP,DUST (LOW SIDE SERVICE PORT) | |||
| XA4445 | CAP,DUST(1/4"SWITCH PORT) | |||
| 15 | PC1969 | ADAPTER | ||
| 16 | PC2268 | RECEIVER DRIER | ||
| 17 | PC1341 | BRACKET | ||
| 18 | MM0027 | CAPSCREW-M6×1.00×25 | ||
| 19 | MM0459 | FLAT WASHER-M6 | ||
| 20 | C5746 | CAPSCREW-1/4"-20NC×3/4" | ||
| 21 | C5774 | LOCKWASHER-1/4" | ||
| 22 | PC1804 | SWITCH,TRINARY | 1 | |
| 23 | HA8636 | HOSE | ||
| 24 | 58B-07-20000 | ADAPTER | ||
| 25 | VZ4843 | TYRAP | 10 | |
| CAB GROUP | ||||
| STEERING COLUMN XB8878 | ||||
| ltem | Part No | Description | Qty | |
| 1 | BF5167 | KIT,GAP HIDER | 1 | |
| 2 | XA5621 | CONTACT ASSEMBLY,HORN | ||
| XA4890 | SPRING | |||
| 3 | BF5169 | KIT,ROD AND PAWL | ||
| 4 | BF5170 | KIT,TILT BOLT | ||
| 5 | VE4299 | COVER | ||
| 6 | BF5171 | KIT,TILT LEVER | ||
| 7 | BF2071 | KIT,TILT STOP | ||
| 8 | BF5176 | KIT,EXTENSION SPRING | ||
| 9 | BF5172 | KIT,COVER(UPPER &LOWER) | ||
| 10 | BF5173 | KIT,KNOB | ||
| 11 | BF5174 | KIT,TELESCOPE LINK | ||
| 12 | BF5175 | NUT | ||
| NS | NOTE:NS=NOT SHOWN | |||
| NS | VE4309 | BRACKET,MOUNTING | ||
| NS | VE4310 | CAPSCREW-3/8"-24NF | 2 | |
| NS | VE4311 | LOCKWASHER-3/8" | 2 | |
| CAB GROUP | ||||
| STEERING COLUMN INSTALLATION | ||||
| ltem | Part No | Description | Qty | Ref |
| 1 | PC0683 | WHEEL,STEERING | 1 | |
| 2 | PC1621 | BUTTON,HORN | 1 | |
| 3 | 58F-40-00180 | STEERING COLUMN ASSEMBLY | 1 | |
| XB8878 | COLUMN,STEERING(SEE INDEX) | 1 | 56116 | |
| 4 | 58F-54-00020 | MULTI-FUNCTION SWITCH ASSEMBLY | 1 | |
| WB3105 | FLAT WASHER-M7 | 2 | ||
| WB3104 | FLAT WASHER-M5 | 2 | ||
| WB3103 | LOCKWASHER-M5 | 2 | ||
| 58F-09-00000 | CAPSCREW-M5×0.8×45 | 2 | ||
| 08021-00400 | CONNECTOR | 1 | ||
| VZ4843 | TYRAP | 1 | ||
| 5 | MM0604 | CAPSCREW-M10×1.50×20 | 4 | |
| 6 | C1547 | FLAT WASHER-3/8" | 4 | |
| 7 | MM0471 | LOCKWASHER-M10 | 4 | |
| CAB GROUP | ||||
| BRAKE VALVE SUB-ASSEMBLY 1/2 BF1851 | ||||
| Item | Part No | Description | Qty | |
| 1 | VE9420 | BOOTCAPASSEMBLY(2) | 1 | |
| 2 | BOOT(1)(2) | 1 | ||
| 3 | VE8544 | SCREW(SPECIAL) | 4 | |
| 4 | VE8545 | PLATE,RETAINER | 1 | |
| 5 | VE8546 | SCREW | 2 | |
| 6 | VE9419 | ACTUATOR BASE | 1 | |
| 7 | VE8547 | NSERT | 4 | |
| NS | NOTE:(1)NOT SERVICED SEPARATELY. | |||
| NS | VE8530 | (2)INCLUDED IN VE8530 BOOT KIT. | ||
