| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| CAB GROUP | ||||
| SEAT ASSEMBLY 1/258E-57-00501 | ||||
| Item | Part No | Description | Qty | Ref |
| 1 58E-98-10120 CUSHION,SEAT 1 | ||||
| 2 58E-98-10130CUSHION,BACKREST 1 | ||||
| 3 58E-98-10540HEADREST 1 | ||||
| 4 XA4061 KIT,HEADREST GUIDE 1 | ||||
| 5 58E-98-10240 BRACKET,HEADREST GUIDE 1 | ||||
| 6 XA5119 RIVET 4 | ||||
| 7 58E-98-10300 SCREW-#12 2 | ||||
| 8 58E-98-10110 KIT,HIGHBACK SEAT 1 | ||||
| 9 EM4054 SLIDE ASSEMBLY 1 | ||||
| 10 58E-98-10350 CAPSCREW-M8×1.25×30 2 | ||||
| 11 58E-98-10340 FLAT WASHER 6 | ||||
| 12 58E-98-10250 SPACER 4 | ||||
| 13 XA4455 LOCKNUT-M8 4 | ||||
| 14 EM4066 BLOCK,SLIDER(ADJUSTABLE) 2 | ||||
| 15 EM4068 SCREW,ALLEN HEAD-1/4”-20NCX1/2" 2 | ||||
| 16 XA5816 SEAT SUSPENSION ASSEMBLY(SEE INDEX)1 42738 | ||||
| 17 EM4056 RISER 1 | ||||
| 18 EM4078 CAPSCREW-M8×1.25×25 6 | ||||
| 19 EM4059 BLOCK,SLIDER(NON-ADJUSTABLE) 2 | ||||
| 20 58E-98-10280 BOLT,CARRIAGE-5/16"-18NC 2 | ||||
| 21 58E-98-10330 LOCKNUT-5/16"-18NC 2 | ||||
| 22 58E-98-10390 CAPSCREW-5/16"-18NC×11/2" 2 | ||||
| 23 58E-98-10200 SPACER 1 | ||||
| 24 EM4072 NUT,CENTERLOCK-5/16"-18NC 2 | ||||
| 25 58E-98-10232 BRACKET,RECLINE STOP | ||||
| CAB GROUP | ||||
| OPERATOR SEAT INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | 58E-57-00501 | SEAT ASSEMBLY.OPERATOR(SEE INDEX) | 1 | 43660 |
| 2 | TR4731 | CAPSCREW-5/16"-18NCX1" | 4 | |
| 3 | TV0177 | FLAT WASHER-5/16" | 4 | |
| 4 | SC4174 | LOCKWASHER-5/16" | 4 | |
| 5 | EM2889 | HARNESS,SEAT | ||
| 6 | EM8613 | HARNESS,SEAT JUMPER | ||
| 7 | VH5017 | TIE,CABLE | ||
| 8 | VP4693 | GROMMET | ||
| 9 | 08193-21012 | CLIP | ||
| 10 | MM0605 | CAPSCREW-M10×1.50×25 | ||
| 11 | MM0471 | LOCKWASHER-M10 | ||
| 12 | MM0461 | FLAT WASHER-M10 | ||
| 13 | WB1301 | CLAMP,CUSHION-1/4" | 1 | |
| CAB GROUP | ||||
| CAB LIGHTS | ||||
| Item | Part No | Description | Qty | |
| 1 | EM8073 | LIGHT,BRAKE-RED | 1 | |
| 2 | EM8074 | LIGHT,RETARD-AMBER | 1 | |
| 3 | WA5654 | SCREW | 3 | |
| 4 | VE5837 | LIGHT,DOME | ||
| VE8635 | LENS,PLASTIC | |||
| VE8636 | SWITCH | |||
| VZ1912 | BULB | |||
| XB5532 | TUBE,FLEX | 2 | ||
