Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| INSTRUMENT PANEL ASSEMBLY X83-00-05181 | ||||
| ltem | Part No | Description | Qty | Ref |
| 1 | PC3385 | GAUGE PANEL(SEE FIG 61325) | 1 | 61325 |
| 2 | PB8658 | SCREW-M6×1.00×30 | 4 | |
| 3 | EK7947 | LOUVER,RECTANGULAR | 2 | |
| 4 | XB8077 | DASH MODULE.UPPER RH (SEEFIG 43488) | 1 | 43488 |
| 5 | 58F-54-00600 | DASH MODULE.LOWER RH(SEEFIG 43487 | 1 | 43487 |
| 6 | 58E-93-00490 | DECAL,SHIFT SELECTOR(SPANISH)(1) | 1 | |
| 7 | WB3292 | DECAL,WARNING(KEY SWITCH)(SPANISH)(1) | 1 | |
| 8 | DC9822 | DRIVE SCREW | 4 | |
| 9 | SM2648 | PLATE,SEAL RETAINER-RH | 1 | |
| 10 | SM2646 | PLATE,SEAL RETAINER-LH | 1 | |
| 11 | PB9829 | SCREW-M6×1.00×16 | 10 | |
| 12 | TX7829 | SEAL,STEERING COLUMN | 1 | |
| 13 | EL3494 | DASH MODULE.LOWERLH (SEEFIG 61324) | 1 | 61324 |
| 14 | EK8962 | SEAL,LOWER MODULE | 2 | |
| 15 | EK8961 | SEAL,UPPER MODULE | 2 | |
| 16 | PC3588 | PANEL,STATUSLIGHT | 1 | |
| 17 | SM2466 | SCREW-#10-24NCX1" | 4 | |
| 18 | EL5675 | DASH PANEL,MOLDED | 1 | |
| 19 | SM5145 | TUBE(1) | 2 | |
| 20 | WA4513 | SCREW-#10-24NC×1/2"(1) | 4 | |
| 21 | CC6103 | CLAMP,WORM DRIVE(FOR AIR HOSES) | 4 | |
| 22 | SM2783 | HOSE,AIR(TO RECTANGULAR LOUVERS) | 2 | |
| 23 | EK7946 | ADAPTER,HOSE | 2 | |
| PC1938 | HARNESS-MAIN GAUGE PANEL | 1 | ||
| PC1939 | HARNESS-WARNING PANEL | 1 | ||
| NS | NOTE:(1)NOT INCLUDED IN THE INSTRUMENT PANELASSEMBLY. | |||
| CAB GROUP | ||||
| REAR SPEAKER INSTALLATION | ||||
| Item | Part No | Description | Qty | |
| 1 | WA3367 | NUT ASSEMBLY | 8 | |
| 2 | PC0724 | SPEAKER | 2 | |
| 3 | 31127R1 | CAPSCREW-M6X1.00X12 | 5 | |
| 4 | EL2692 | PANEL | 1 | |
| 5 | PB8658 | SCREW-M6X1.00×30 | 4 | |
| 6 | EL2946 | HARNESS,SPEAKER | 2 | |
| CAB GROUP | ||||
| RADIO ANTENNAINSTALLATION | ||||
| Item | Part No | Description | Qty | |
| 1 | PB9957 | CABLE,ANTENNA EXTENSION | 1 | |
| 2 | EJ7875 | ADAPTER,ANTENNA | 1 | |
| 3 | VY2784 | GROMMET | 1 | |
| 4 | PB9916 | CABLE,ANTENNA EXTENSION | 1 | |
| 5 | TG2562 | CLAMP,VINYL-1/2" | 2 | |
| 6 | PB9985 | ANTENNA,RADIO | 1 | |
| CAB GROUP | ||||
| DIMMER TIMER MODULE | ||||
| Item | Part No | Description | Qty | |
| 1 | XB9656 | PLATE,MOUNTING | 1 | |
| 2 | PC2422 | TIMER(LOW FUEL BUZZER) | 1 | |
| 3 | MM0373 | NUT-M5×0.8 | 3 | |
| 4 | MM0379 | LOCKWASHER-M5 | 3 | |
| 5 | MM0459 | FLAT WASHER-M6 | 3 | |
| 6 | XB9657 | HARNESS,DIMMER | 1 | |
| 7 | 08193-21012 | CLIP | 1 | |
| 8 | VY3109 | CLAMP,VINYL-1/16" | 1 | |
