Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| ALTERNATOR MODEL 5GTA41B3 | ||
| PART NO. |
DESCRIPTION | |
| 5GTA41B | ALTERNATOR (SEE PB-40029-005) | |
| 84A203180P1 | CARBON BRUSH | |
| 41B532481P4 | SUPPORT WITH INSULATED STUD AND KEY | |
| 41B531649G2 | BRUSHHOLDER | |
| 41A232946G1 | PRESSURE ARM | |
| 41A232943P1 | SPRING | |
| 41A231194P1 | WASHER, BRASS, 11/16 IN OD | |
| N533P2522 | PIN, SPRING DOWEL, 1/4 IN DIA, 1 3/8 IN LONG | |
| 41A230733P4 | BOLT W/WASHER, SL HX HD, 1/4 IN-20, 1/2 IN LONG | |
| N22P23020B13 | BOLT, HEX HD, 5/16 IN-18, 1 1/4 IN LONG | |
| N203P23B13 | NUT, HEX, 5/16 IN-18 | |
| 41B538384G8 | CABLE ASSEMBLY | |
| 41B538384G9 | CABLE ASSEMBLY | |
| 41B539064P13 | CABLE MARKER (MARKED F1) | |
| 41B539064P14 | CABLE MARKER (MARKED F2) | |
| 8809650P1 | WASHER, CONCAVE, 1/4 IN, SPR STL | |
| N26P21012B13 | BOLT, SL HEX HD, 1/4 IN-20, 3/4 IN LONG | |
| 41B532401G9 | CABLE ASSEMBLY, SPEED SENSOR | |
| 41A264911P1 | CONNECTOR, 0.125 IN TO 0.250 IN DIA CABLE | |
| 41A235260P1 | INSULATOR, 1 3/8 IN THICK, 1 3/4 IN OD | |
| 41A235261P2 | STUD, 1 IN LONG | |
| 497A806P83 | CEMENT | |
| 41B537660P1 | WASHER, FLAT, 0.435 IN ID, 0.675 IN OD | |
| 41B537660P6 | WASHER, FLAT, 0.562 IN ID, 0.938 IN OD | |
| 41C635792P2 | SPACER, 0.250 IN THICK | |
| 41C635792P4 | PLATE, CLAMPING | |
| 41C635792P8 | CLAMP, 0.850 IN THICK, THREE SLOTS | |
| N22P23020B13 | BOLT, HEX HD, 5/16 IN-18, 1 1/4 IN LONG | |
| N22P23028B13 | BOLT, HEX HD, 5/16 IN-18, 1 3/4 IN LONG | |
| N22P25012B13 | BOLT, HEX HD, 3/8 IN-16, 3/4 IN LONG | |
| N22P25060B13 | BOLT, HEX HD, 3/8 IN-16, 3 3/4 IN LONG | |
| N22P29024B13 | BOLT, HEX HD, 1/2 IN-13, 1 1/2 IN LONG | |
| N203P23B13 | NUT, HEX, 5/16 IN-18 | |
| N402P42B13 | WASHER, 5/16 IN | |
| N405P42B13 | LOCKWASHER, 5/16 IN | |
| 84B517229G1 | TERMINAL, MAIN CONNECTION | |
| 84C620849G13 | CABLE ASSEMBLY (T1) | |
| 84C620849G14 | CABLE ASSEMBLY (T2) | |
| 84C620849G15 | CABLE ASSEMBLY (T3) | |
| 84C620983P1 | COVER, MAIN CONNECTION | |
| 41A262893P3 | MAGNETIC PICKUP, SPEED SENSOR | |
| 84C620844P2 | HUB | |
| 41A235861P2 | DOWEL PIN | |
| 84C620949G1 | ADAPTER | |
| 84D707047G3 | STATOR ASSEMBLY | |
| 84D707047G2 | STATOR REWIND KIT | |
| 41C635787G15 | STATOR FRAME AND CORE ASSEMBLY | |
| 41C636067G2 | CONNECTION STRAP, INSULATED, 81.75 IN DEV LGTH | |
| 41B537038G1 | BRACKET, INSULATED | |
| 41B535823G1 | BRACKET, INSULATED | |
| N22P29016B13 | BOLT, HEX HD, 1/2 IN-13, 1 IN LONG | |
| 41B537660P6 | WASHER, FLAT, 0.562 IN ID, 0.938 IN OD | |
| 41B535564G6 | CABLE ASSEMBLY, 11 1/4 IN LONG | |
| 41A231281P457 | BRAZING STRIP, 3/8 IN X 1 1/2 IN, 0.005 IN THK | |
| 41B538372G1 | CONNECTION STRAP, INSULATED | |
| 41B537912G1 | INSULATOR WITH STUD | |
| N258P25B13 | NUT, HEX, 3/8 IN-16 | |
| 41B535670P3 | COVER | |
| 41A239348P2 | INSULATION PAD, 5 IN LONG | |
| 41A235261P2 | STUD, 1 IN LONG | |
| N22P25012B13 | BOLT, HEX HD, 3/8 IN-16, 3/4 IN LONG | |
| N405P43B13 | LOCKWASHER, 3/8 IN | |
| 41A239654P1 | GROMMET, SYNTHETIC RUBBER, 1/2 IN ID | |
| 41B539064P71 | CABLE MARKER (MARKED T19) | |
| 41B539064P46 | CABLE MARKER (MARKED T20) | |
| N402P43B13 | WASHER, 3/8 IN | |
| 41B538426P1 | FRONT PLATE | |
| 84D730106G1 | ROTOR ASSEMBLY | |
| 41B532458G1 | CORE, ROTOR | |
| 84D730152P1 | SHAFT, ROTOR | |
| 41C637809G3 | ROTOR COIL WITH POLE PIECE | |
| 41A330750P1 | COIL BRACE | |
| 41A235755P2 | SLIPPER STRIP, 44 IN LONG, 0.010 IN THK, SPRING STL | |
| 41C637815G2 | COLLECTOR RING ASSEMBLY | |
| 41A235776P1 | CONNECTION STRAP, 7.20 IN DEV LENGTH | |
| 41B539014P1 | TIE RING | |
| 41A239176P21 | GLASS TAPE, 0.015 IN THICK, 1 IN WIDE | |
| 186V942P1 | FASTENING | |
| 8864950P338 | BALL BEARING | |
| 84C620825P1 | BEARING HOUSING, 13 3/4 IN OD | |
| 84C620826P1 | BEARING CAP, 10 3/4 IN OD | |
| 84B515201P1 | FLINGER, 6 9/16 IN OD | |
| 84B515203P1 | SLEEVE, 5 3/8 IN OD | |
| 84A206963P1 | SEAL | |
| 41B537696P1 | GASKET, 0.031 IN THK | |
| N22P33052B13 | BOLT, HEX HD, 5/8 IN-11, 3 1/4 IN LONG | |
| 41B537660P9 | WASHER, FLAT, 0.725 IN ID, 1 IN OD | |
| 84B515204P1 | HUB, 5 3/16 IN OD | |
| 41A231281P46 | BRAZING STRIP, 1 IN X 1 IN LONG | |
| 2766829ADP15 | BALANCE WEIGHT, 10 1/2 IN OD, 3/4 IN WIDE | |
| 2766829ADP54 | BALANCE WEIGHT, 1 1/2 IN WIDE, 3/4 IN THICK | |
| 41A238730P1 | END PLATE | |
| 41A330204P8 | LUBRIPLATE | |
| 84D730143G1 | IMPELLER | |
| 84D730164G1 | FRAMEHEAD | |
| 84E901339G2 | INLET HOUSING | |
| 84E901340G1 | OUTLET HOUSING | |
| N14P32036 | BOLT, HEX HD, 5/8 IN 18, 2 1/4 IN LONG | |
| N22P25028B13 | BOLT, HEX HD,3/8 IN-16, 1 3/4 IN LONG | |
| N14P29024B13 | BOLT, HEX HD, GRADE 8, 1/2 IN-13, 1 1/2 IN LONG | |
| N22P29072B13 | BOLT, HEX HD, 1/2 IN-13, 4 1/2 IN LONG | |
| N22P33028 | BOLT, HEX HD, 5/8 IN-11, 1 3/4 IN LONG | |
| N22P33036B13 | BOLT, HEX HD, 5/8 IN-11, 2 1/4 IN LONG | |
| 41B537660P1 | WASHER, FLAT, 0.435 IN ID, 0.675 IN OD | |
| 41B537660P6 | WASHER, FLAT, 0.562 IN ID, 0.938 IN OD | |
| 41B537660P9 | WASHER, FLAT, 0.725 IN ID, 1 IN OD | |
| 41B537660P12 | WASHER, FLAT, 0.725 IN ID, 2 IN OD | |
| N258P25B13 | NUT, HEX, 3/8 IN-16 | |
| N509P5022B | PIN, SPRING DOWEL, 1/2 IN, 1 3/8 IN LONG | |
| N5700P71 | PIPE PLUG, 1 IN, SQ HD | |
| 497A806P60 | ADHESIVE, RTV SILMATE 1473 | |
| 499A906AAP4 | NUT, HEX, 3/8 IN-16, SELF-LOCKING | |
| 41B539088ABG1 | COVER ASSEMBLY | |
| 41B539090P1 | FRONT PLATE WITH TWO HOLES | |
| 84C620937G1 | COVER ASSEMBLY | |
| 84C620937P2 | GASKET | |
| 4732253G2 | LATCH | |
| 497A806P12 | CEMENT | |
| N22P25012B13 | BOLT, HEX HD, 3/8 IN-16, 3/4 IN LONG | |
| N22P25016B13 | BOLT, HEX HD, 3/8 IN-16, 1 IN LONG | |
| N402P43B13 | WASHER, 3/8 IN | |
| N405P43B13 | LOCKWASHER, 3/8 IN | |
