| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| RH DECK HANDRAILS | ||
| Item | Part No | Description |
| 1 | XB1606 | HANDRAIL-RH DECK(REAR) |
| 2 | XB6413 | HANDRAIL-RH DECK (SIDE) |
| 3 | MM0619 | CAPSCREW-M12X1.75×35 |
| 4 | MM0714 | FLAT WASHER-M12 |
| 5 | MM0694 | LOCKNUT-M12×1.75 |
| 6 | EM1220 | HANDRAIL-RH DECK(FRONT) |
| 7 | MM0472 | LOCKWASHER-M12 |
| 8 | MM0462 | FLAT WASHER-M12 |
| 9 | MM0618 | CAPSCREW-M12×1.75×30 |
| 10 | C5762 | CAPSCREW-5/8"-11NCX11/2" |
| 11 | VC1390 | LOCKWASHER-5/8" |
| 12 | C1525 | NUT-5/8"-11NC |
| FRAME&DECK GROUP | ||
| LH DECK HANDRAILS | ||
| Item | Part No | Description |
| 1 | XB6269 | HANDRAIL-LH DECK (REAR) |
| 2 | EM1484 | PLATE,BENT |
| 3 | XB6291 | HANDRAIL-LH DECK(FRONT) |
| 4 | PC2322 | SPRING,LH GATE LATCH |
| 5 | EL3986 | SPACER |
| 6 | EM0558 | PLATE,BENT |
| 7 | MM0619 | CAPSCREW-M12×1.75×35 |
| 8 | MM0472 | LOCKWASHER-M12 |
| 9 | EM9722 | HANDRAIL |
| 10 | EM0561 | PLATE,BENT |
| 11 | MM0624 | CAPSCREW-M12×1.75×70 |
| 12 | MM0714 | FLAT WASHER-M12 |
| 13 | MM0694 | LOCKNUT-M12X1.75 |
| 14 | MM0618 | CAPSCREW-M12X1.75×30 |
| 15 | XB6264 | HANDRAIL-LH DECK (SIDE) |
| 16 | EM4797 | HANDRAIL |
| 17 | XB1217 | GATE |
| 18 | MM0620 | CAPSCREW-M12X1.75×40 |
| 19 | XB4716 | BUMPER |
| 20 | MM0179 | NUT-M12X1.75 |
| 21 | MM0608 | CAPSCREW-M10×1.50×40 |
| 22 | MM0471 | LOCKWASHER-M10 |
| 23 | MM0713 | FLAT WASHER-M10 |
| 24 | MM0461 | FLAT WASHER-M10 |
| 25 | MM0178 | NUT-M10×1.50 |
| COOLING SYSTEM | ||
| Item | Part No | Description |
| 38 | VE3475 | TUBE |
| 39 | BF2772 | X-BRACE ROD |
| 40 | VE1219 | END,TUBE STAY |
| COOLING SYSTEM | ||
| RADIATOR INSTALLATION RADIATOR &SHROUD ASSEMBLY PC2616 |
||
| Item | Part No | Description |
| 1 | XA3514 | RADIATOR,JACKET WATER(HTC)(SEE FIG41814) |
| 2 | XA3515 | RADIATOR.AFTERCOOLER(LTC)(SEE FIG41814) |
| 3 | BF5349 | TANK,SURGE |
| 4 | XA4888 | SHROUDFAN |
| 5 | XA2832 | COOLER.FUEL(SEE FIG 41833) |
| 6 | XA3516 | RING,FAN |
| 7 | (NOT USED IN THISAPPLICATION) | |
| 8 | C1614 | CAPSCREW-1/2"-13NCX11/2" |
| 9 | C1540 | LOCKWASHER-1/2" |
| 10 | VE3460 | CAPSCREW,HEX HEAD(HEAVY-DUTY) |
| 11 | C1602 | CAPSCREW-3/8”-16NC×1" |
| 12 | C0312 | LOCKWASHER-3/8" |
| 13 | C1521 | NUT-3/8”-16NC |
| 14 | BF3625 | GAUGE,SIGHT |
| 15 | XA3517 | HOSE,OVERFLOW |
| 16 | VE1474 | CAP-14 PSI |
| 17 | VE4441 | ELBOW |
| 18 | BF4463 | ADAPTER |
| 19 | BF4461 | ELBOW |
| 20 | BF4460 | HOSE |
| 21 | BF4462 | SWIVEL |
| 22 | VE4440 | WASHER |
| 23 | VE3461 | NUT,HEXHEAD |
| 24 | VE1223 | CLIP |
| 25 | E3735 | FLAT WASHER-5/16" |
| 26 | VE8326 | BUSHING,REDUCER-HEX |
| 27 | BF4464 | FITTING |
| 28 | 58B-03-00190 | LOCKWASHER-3/8" |
| COOLING SYSTEM | ||
| RADIATOR INSTALLATION | ||
| Item | Part No | Description |
| 1 | BF5349 | TANK,SURGE(INCLUDED IN RADIATOR ASSEMBLY) |
| 2 | PC2616 | RADIATOR AND SHROUDASSEMBLY(SEE INDEX) |
| 3 | E3909 | CAPSCREW-1"-8NC×31/4" |
| 4 | VH8186 | LOCKNUT-1"-8NC |
| 5 | C1532 | NUT,HEX |
| 6 | PB6831 | END,ROD |
| 7 | TY5096 | ROD,THREADED |
| 8 | C1667 | CAPSCREW-1"-8NC×21/2" |
| 9 | MM0038 | CAPSCREW-M16×2.00×35 |
| 10 | MM0706 | FLAT WASHER-M16 |
| 11 | 58E-80-20400 | SUPPORT,RADIATOR |
| 12 | 58E-80-20300 | SUPPORT,RADIATOR(RH) |
| 58E-80-20310 | SUPPORT,RADIATOR(LH) | |
| 13 | ED9895 | FLAT WASHER |
| 14 | PC0780 | MOUNT,RUBBER-TWO PIECE |
| 15 | C1648 | CAPSCREW-3/4"-10NC×3" |
| 16 | WA0362 | FLAT WASHER-3/4" |
| 17 | C1542 | LOCKWASHER-3/4" |
| 18 | C1527 | NUT-3/4"-10NC |
