| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| FIG. | REF. | |
| NO. | PART NO. | DESCRIPTION |
| 146 | N430P3 | WASHER,HARDENED,3/8 IN |
| 147 | N402P9B13 | WASHER,NO 10(NARROW) |
| 149 | N402P11B13 | WASHER,1/4 IN(NARROW) |
| 150 | N22P21014B13 | BOLT,HEX HD,1/4 IN-20,7/8 INLONG |
| 152 | 41A250668P71 | WASHER,0.406ID |
| 153 | N22P29016B13 | BOLT,HEX HD,1/2 IN-13,1 INLONG |
| 154 | 41A279870P28 | STUD,3/8 IN-16,23/4 INLONG |
| CENTER DECK HANDRAIL | ||
| Item | Part No | Description |
| 1 | EM1347 | HANDRAIL,CENTER DECK 1 |
| 2 | MM0618 | CAPSCREW-M12X1.75×30 14 |
| 3 | MM0472 | LOCKWASHER-M12 14 |
| 4 | MM0714 | FLAT WASHER-M12 14 |
| FRAME & DECK GROUP | ||
| Item | RH&DIAGONAL LADDER HANDRAILS | |
| 1 | Part No | Description |
| 2 | EM4796 | HANDRAIL |
| 3 | EM4792 | GATE,RH |
| 4 | XB1311 | HANDRAIL |
| 5 | MM0619 | CAPSCREW-M12X1.75×35 |
| 6 | MM0714 | FLAT WASHER-M12 |
| 7 | MM0472 | LOCKWASHER-M12 |
| 8 | MM0179 | NUT-M12×1.75 |
| 9 | MM0620 | CAPSCREW-M12X1.75×40 |
| 10 | MM0462 | FLAT WASHER-M12 |
| 11 | MM0694 | LOCKNUT-M12×1.75 |
| 12 | PC2325 | SPRING,LATCH |
| 13 | EM0561 | PLATE,BENT |
| 14 | EL3986 | SPACER |
| 15 | EM0558 | PLATE,BENT |
| 16 | MM0624 | CAPSCREW-M12×1.75X70 |
| 17 | MM0012 | CAPSCREW-M16×2.00×25 |
| 18 | MM0706 | FLAT WASHER-M16 |
| 19 | EM2742 | PLATE |
| 20 | EM5080 | HANDRAIL,STAIR |
| 21 | MM0618 | CAPSCREW-M12X1.75×30 |
| 22 | EM2731 | HANDRAIL,RH VERTICAL LADDER |
| 23 | MM0624 | CAPSCREW-M12×1.75X70 |
| 24 | FRAME&DECK GROUP | |
| 25 | LH LADDER HANDRAILS | |
| 26 | Part No | Description |
| 27 | EM5026 | HANDRAIL,LH VERTICAL LADDER(LONG) |
| 28 | MM0620 | CAPSCREW-M12X1.75×40 |
| 29 | MM0714 | FLAT WASHER-M12 |
| 30 | MM0472 | LOCKWASHER-M12 |
| 31 | MM0179 | NUT-M12X1.75 |
| 32 | EM1120 | HANDRAIL,LH PLATFORM |
| 33 | EM2954 | HANDRAIL,LH PLATFORM |
| 34 | MM0624 | CAPSCREW-M12×1.75×70 |
| 35 | EL0828 | FLAT |
| 36 | MM0694 | LOCKNUT-M12X1.75 |
| 37 | MM0618 | CAPSCREW-M12×1.75×30 |
| 38 | EM2732 | HANDRAIL,LH PLATFORM |
| 39 | XB3973 | HANDRAIL,LH VERTICAL LADDER(SHORT,UPPER) |
| 40 | XB3977 | HANDRAIL,LH VERTICAL LADDER(SHORT,LOWER) |
| 41 | FRAME &DECK GROUP | |
| 42 | RETARDING GRID HANDRAILS | |
| 43 | Part No | Description |
| 44 | 58E-54-13820 | HANDRAIL,GRID BOX(REAR) |
| 45 | EM5037 | HANDRAIL,GRID BOX (SIDE) |
| 46 | TY9258 | STRIP,ANTI-SLIP |
| 47 | EM4804 | GUARD,RH |
| 48 | MM0619 | CAPSCREW-M12×1.75×35 |
| 49 | MM0462 | FLAT WASHER-M12 |
| 50 | MM0694 | LOCKNUT-M12X1.75 |
| 51 | 58E-54-13870 | BRACKET |
| 52 | EL9093 | BRACKET |
| 53 | VC6500 | CAPSCREW-1/2"-13NCX2" |
| 54 | TR5445 | LOCKWASHER-1/2" |
| 55 | TR6008 | FLAT WASHER-1/2" |
| 56 | 1602 | CAPSCREW-3/8"-16NCX1" |
| 57 | TC1231 | LOCKWASHER-3/8" |
| 58 | TR4436 | FLAT WASHER-3/8" |
| 59 | EM4817 | GUARD,LH |
| 60 | FRAME&DECK GROUP | |
