| Item Part No Description Qty |
| 0 XA3515 RADIATOR,AFTERCOOLER(LTC) 1 |
| 1 XA2836 MEMBER,SDE 1 |
| 2 XA2837 MEMBER,SIDE 1 |
| 3 XA3532 TANK,CENTER 1 |
| 4 XA3533 TANK 1 |
| 5 XA3534 TANK 1 |
| 6 XA3535 SUPPORT,CENTER 2 |
| 7 C0312 LOCKWASHER-3/8" 8 |
| 8 C1602 CAPSCREW-3/8"-16NCX1" 8 |
| 9 C1540 LOCKWASHER-1/2" 20 |
| 10 VE3460 CAPSCREW,HEX HEAD(HEAVY-DUTY)20 |
| 11 XA2721 SEAL,RUBBER LOCKING 512 |
| 12 XA2720 SEAL,RUBBER 512 |
| 13 VE3475 TUBE 276 |
| 14 BF0634 TUBE ASSEMBLY 236 |
| 15 VE1219 END,TUBE STAY 8 |
| 16 BF0819 BAFFLE,BOTTOM 4 |
| 17 BF0818 BAFFLE,TOP 4 |
| XA3514 RADIATOR,JACKET WATER(HTC) 1 |
| 18 XA3528 TANK 1 |
| 19 XA3529 TANK,CENTER 1 |
| 20 XA3530 TANK 1 |
| 21 XA2844 MEMBER,SDE 1 |
| 22 XA2845 MEMBER,SIDE 1 |
| 23 XA3531 SUPPORT,CENTER 2 |
| 24 C1528 NUT-3/4"-16NF 12 |
| 25 VE1285 BRACKET,X-BRACE 2 |
| 26 XA2721 SEAL,RUBBER LOCKING 780 |
| 27 XA2720 SEAL,RUBBER 780 |
| 28 VE7648 BAFFLE,AIR 2 |
| 29 VE7649 BAFFLE,AIR 2 |
| 30 C1540 LOCKWASHER-1/2" 20 |
| 31 VE3460 CAPSCREW,HEX HEAD(HEAVY-DUTY)20 |
| 32 C0312 LOCKWASHER-3/8" 8 |
| 33 C1602 CAPSCREW-3/8"-16NCX¹" 8 |
| 34 XA2806 FLAT WASHER-5/16" 6 |
| 35 C5747 CAPSCREW-5/16"-18NCX3/4" 4 |
| 36 VE6312 NUT,HEX HEAD 2 |
| 37 BF0634 TUBE ASSEMBLY 476 |
| Item Part No Description Qty |
| 0 XA3515 RADIATOR,AFTERCOOLER(LTC) 1 |
| 1 XA2836 MEMBER,SIDE 1 |
| 2 XA2837 MEMBER,SIDE 1 |
| 3 XA3532 TANK,CENTER 1 |
| 4 XA3533 TANK 1 |
| 5 XA3534 TANK 1 |
| 6 XA3535 SUPPORT,CENTER 2 |
| 7 C0312 LOCKWASHER-3/8" 8 |
| 8 C1602 CAPSCREW-3/8"-16NC×1" 8 |
| 9 C1540 LOCKWASHER-1/2" 20 |
| 10 VE3460 CAPSCREW,HEX HEAD(HEAVY-DUTY)20 |
| 11 XA2721 SEAL,RUBBER LOCKING 512 |
| 12 XA2720 SEAL,RUBBER 512 |
| 13 VE3475 TUBE 276 |
| 14 BF0634 TUBE ASSEMBLY 236 |
| 15 VE1219 END,TUBE STAY 8 |
| 16 BF0819 BAFFLE,BOTTOM 4 |
| 17 BF0818 BAFFLE,TOP 4 |
| XA3514 RADIATOR,JACKET WATER(HTC) 1 |
| 18 XA3528 TANK 1 |
| 19 XA3529 TANK,CENTER 1 |
| 20 XA3530 TANK 1 |
| 21 XA2844 MEMBER,SIDE 1 |
| 22 XA2845 MEMBER,SIDE 1 |
| 23 XA3531 SUPPORT,CENTER 2 |
| 24 C1528 NUT-3/4"-16NF 12 |
| 25 VE1285 BRACKET,X-BRACE 2 |
| 26 XA2721 SEAL,RUBBER LOCKING 780 |
| 27 XA2720 SEAL,RUBBER 780 |
| 28 VE7648 BAFFLE,AIR 2 |
| 29 VE7649 BAFFLE,AIR 2 |
| 30 C1540 LOCKWASHER-1/2" 20 |
| 31 VE3460 CAPSCRE,HEX HEAD(HEAVY-DUTY)20 |
| 32 C0312 LOCKWASHER-3/8" 8 |
| 33 C1602 CAPSCREW-3/8"-16NCX1" 8 |
| 34 XA2806 FLAT WASHER-5/16" 6 |
| 35 C5747 CAPSCREW-5/16"-18NCX34" 4 |
| 36 VE6312 NUT,HEX HEAD 2 |
| 37 BF0634 TUBE ASSEMBLY 476 |
| 38 VE3475 TUBE 304 |
| 39 BF2772 X-BRACE ROD 2 |
| Item Part No Description Qty |
| 0 XA3515 RADIATOR,AFTERCOOLER(LTC) 1 |
| 1 XA2836 MEMBER,SIDE 1 |
| 2 XA2837 MEMBER,SIDE 1 |
| 3 XA3532 TANK,CENTER 1 |
| 4 XA3533 TANK 1 |
| 5 XA3534 TANK 1 |
| 6 XA3535 SUPPORT,CENTER 2 |
| 7 C0312 LOCKWASHER-3/8" 8 |
| 8 C1602 CAPSCREW-3/8"-16NCX1" 8 |
| 9 C1540 LOCKWASHER-1/2" 20 |
| 10 VE3460 CAPSCREW,HEX HEAD(HEAVY-DUTY)20 |
| 11 XA2721 SEAL,RUBBER LOCKING 512 |
| 12 XA2720 SEAL,RUBBER 512 |
| 13 VE3475 TUBE 276 |
| 14 BF0634 TUBE ASSEMBLY 236 |
| 15 VE1219 END,TUBE STAY 8 |
| 16 BF0819 BAFFLE,BOTTOM 4 |
| 17 BF0818 BAFFLE,TOP 4 |
| XA3514 RADIATOR,JACKET WATER(HTC) 1 |
| 18 XA3528 TANK 1 |
| 19 XA3529 TANK,CENTER 1 |
| 20 XA3530 TANK 1 |
| 21 )XA28 44 MEMBER,SIDE 1 |
| 22 XA2845 MEMBER,SIDE 1 |
| 23 XA3531 SUPPORT,CENTER 2 |
| 24 C1528 NUT-3/4"-16NF 12 |
| 25 VE1285 BRACKET,X-BRACE 2 |
| 26 XA2721 SEAL,RUBBER LOCKING 780 |
| 27 XA2720 SEAL,RUBBER 780 |
| 28 VE7648 BAFFLE,AIR 2 |
| 29 VE7649 BAFFLE,AIR 2 |
| 30 C1540 LOCKWASHER-1/2" 20 |
| 31 VE3460 CAPSCREW,HEXHEAD(HEAVY-DUTY)20 |
| 32 C0312 LOCKWASHER-3/8" 8 |
| 33 C1602 CAPSCREW-3/8"-16NCX1" 8 |
| 34 XA2806 FLAT WASHER-5/16" 6 |
| 35 C5747 CAPSCREW-5/16"-18NC×3/4" 4 |
| 36 VE6312 NUT,HEX HEAD 2 |
| 37 BF0634 TUBE ASSEMBLY 476 |
| 38 VE3475 TUBE 304 |
