Terex earthmoving equipment parts
| CAB GROUP | ||||
| OPERATOR SEAT INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | 58E-57-00501 | SEAT ASSEMBLY.OPERATOR(SEE INDEX) | 1 | 43660 |
| 2 | TR4731 | CAPSCREW-5/16"-18NCX1" | 4 | |
| 3 | TV0177 | FLAT WASHER-5/16" | 4 | |
| 4 | SC4174 | LOCKWASHER-5/16" | 4 | |
| 5 | EM2889 | HARNESS,SEAT | ||
| 6 | EM8613 | HARNESS,SEAT JUMPER | ||
| 7 | VH5017 | TIE,CABLE | ||
| 8 | VP4693 | GROMMET | ||
| 9 | 08193-21012 | CLIP | ||
| 10 | MM0605 | CAPSCREW-M10×1.50×25 | ||
| 11 | MM0471 | LOCKWASHER-M10 | ||
| 12 | MM0461 | FLAT WASHER-M10 | ||
| 13 | WB1301 | CLAMP,CUSHION-1/4" | 1 | |
| CAB GROUP | ||||
| CAB LIGHTS | ||||
| Item | Part No | Description | Qty | |
| 1 | EM8073 | LIGHT,BRAKE-RED | 1 | |
| 2 | EM8074 | LIGHT,RETARD-AMBER | 1 | |
| 3 | WA5654 | SCREW | 3 | |
| 4 | VE5837 | LIGHT,DOME | ||
| VE8635 | LENS,PLASTIC | |||
| VE8636 | SWITCH | |||
| VZ1912 | BULB | |||
| XB5532 | TUBE,FLEX | 2 | ||
| CAB GROUP | ||||
| CAB CONNECTOR PLATE AND HOSE FLAP | ||||
| Item | Part No | Description | Qty | |
| 1 | 58E-54-04130 | FLAP,RUBBER | 1 | |
| 2 | MM0594 | CAPSCREW-M8×1.25X25 | 3 | |
| 3 | MM0460 | FLAT WASHER-M8 | 3 | |
| 4 | MM0470 | LOCKWASHER-M8 | 3 | |
| 5 | MM0177 | NUT-M8X1.25 | 3 | |
| 6 | MM0027 | CAPSCREW-M6×1.00X25 | 8 | |
| 7 | MM0469 | LOCKWASHER-M6 | 8 | |
| 8 | XC2554 | PLATE,CONNECTOR | 1 | |
| 9 | PC1701 | FITTING,BULKHEAD COAX | 1 | |
| CAB GROUP | ||||
| PASSENGER SEAT ASSM 2/2 PC2550 | ||||
| Item | Part No | Description | Qty | |
| 1 | EM4056 | RISER | 1 | |
| 2 | XA4454 | FLAT WASHER-M8 | 4 | |
| 3 | XA4455 | LOCK NUT-M8 | 4 | |
| 4 | XA4458 | BOLT,CARRIAGE-M8×20 | 4 | |
| 5 | XA4461 | SUSPENSION ASSEMBLY | 1 | |
| 6 | XA4469 | SHOCK | 1 | |
| 7 | XA4468 | ROLLER,SMALL | 4 | |
| 8 | XA4473 | STRAP,REBOUND | 2 | |
| 9 | 58B-00-00900 | ADJUSTMENT KNOBASSEMBLY | ||
| 10 | XA4472 | HEIGHT ADJUSTMENT LEVER ASSEMBLY | ||
| 11 | XA4484 | HEIGHT ADJUSTMENT COVER,TOP | 1 | |
| 12 | XA4483 | HEIGHT ADJUSTMENT COVER,BOTTOM | 1 | |
| 13 | XA4482 | SCREW | 3 | |
| 14 | XA4470 | ROLLER,LARGE | 2 | |
