Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| CAB GROUP | ||||
| INNER DOOR PANEL-RH 58E-54-10110 | ||||
| Item | Part No | Description | Qty | |
| 1 | SM3010 | HARNESS,POWER WINDOW | 1 | |
| 2 | SL9490 | GROMMET,RUBBER | 1 | |
| 3 | PC3277 | WINDOW REGULATOR AND MOTOR-RH | ||
| 4 | SM5391 | INSULATION,PANEL-RH | ||
| 5 | EL1022 | CAPSCREW-DRILLED | ||
| 6 | SM2165 | BRACKET,DOOR STRAP | ||
| 7 | XB4573 | STRAP,DOOR CHECK | ||
| 8 | SM2322 | CLIP,HAIR PIN | ||
| 9 | WB3560 | CAPSCREW-M8×1.25×12 | 2 | |
| 10 | SM2294 | COVER,INNER ACCESS | 1 | |
| 11 | WB3559 | CAPSCREW-M6×1.00×12 | 8 | |
| 12 | SM0926 | SCREW-M6X1.00 | 4 | |
| 13 | SM2739 | PANEL,INNER-RH | 1 | |
| CAB GROUP | ||||
| CAB WINDOwS | ||||
| Item | Part No | Description | Qty | |
| 1 | SM1094 | GLASS,REAR INSULATED | 1 | |
| 2 | SM2898 | GLASS,LH REAR | 1 | |
| 3 | SM2877 | GLASS,LHFRONT | 1 | |
| 4 | SM2899 | GLASS,WINDSHIELD | 1 | |
| 5 | SM4377 | CHANNEL,RUBBER | 1 | |
| 6 | SM2879 | GLASS,RH FRONT | 1 | |
| 7 | SM2045 | CHANNEL,RUBBER | 1 | |
| 8 | SM2897 | SPACER | 20 | |
| CAB GROUP | ||||
| FRONT ACCESS COVER | ||||
| ltem | Part No | Description | Qty | |
| 1 | ED0108 | SEAL STRIP | 1 | |
| 2 | ED0109 | SEAL STRIP | 2 | |
| 3 | EL1094 | COVER | 1 | |
| 4 | MM0471 | LOCKWASHER-M10 | 12 | |
| 5 | MM0604 | CAPSCREW-M10×1.50×20 | 6 | |
| 6 | ED0110 | SEAL STRIP | 1 | |
| 7 | ED0112 | SEAL STRIP | 2 | |
| 8 | 58F-54-00030 | WING SCREW-M10×1.50 | 5 | |
| 9 | VD4460 | LOCKNUT-1/4"-20NC | 7 | |
| 10 | WA5653 | MACHINE SCREW-1/4"-20NCX1/2" | 7 | |
| 11 | EL1046 | COVER,HINGED | 1 | |
| 12 | SM0190 | HINGE,FRONT COVER | 1 | |
| 13 | PB7001 | FILTER,AIR | ||
| CAB GROUP | ||||
| CAB ACCESS cOVERS | ||||
| Item | Part No | Description | Qty | |
| 1 | EL2941 | PLATE,FLOOR COVER | 1 | |
| 2 | MM0593 | CAPSCREW-M8×1.25×20 | 10 | |
| 3 | 01643-31032 | FLAT WASHER-M8 | 10 | |
| 4 | MM0604 | CAPSCREW-M10×150×20 | 24 | |
| 5 | MM0471 | LOCKWASHER-M10 | 24 | |
| 6 | SM2189 | PLATE,ACCESS-LH FLOOR | 1 | |
| 7 | SM0992 | PLATE,REAR ACCESS-BRAKE &STEERING PIPING | 1 | |
| 8 | XB9053 | PLATE,FRONT ACCESS-BRAKE &STEERING PIPING | ||
| 9 | EL5428 | PLATE,COVER | 1 | |
| 10 | EM8384 | PLATE | ||
| 11 | XB9055 | PLATE,COVER | ||
| CAB GROUP | ||||
| PASSENGER SEAT ASSM 1/2 PC2550 | ||||
| Item | Part No | Description | Qty | |
| 1 | EM4061 | KIT,BELT TETHER | 2 | |
| 2 | PIN,COTTER | 2 | ||
| 3 | PB9772 | EYEBOLT | 2 | |
| 4 | TG3941 | JAM NUT(1) | 2 | |
| 5 | XA4456 | SCREW-#8 | 2 | |
| 6 | XA4457 | SCREW-3/16"×7/16" | 2 | |
| 7 | XA4459 | CAPSCREW-5/16"×3/5" | 4 | |
| 8 | 58F-57-00010 | SEAT BELT,LAP | 1 | |
| 9 | XA4462 | KIT,BOOT | ||
| 10 | 58F-54-01610 | SLIDE ASSEMBLY | ||
| 11 | XA4464 | KIT,LUMBAR ASSEMBLY | ||
| 12 | XA4465 | SEAT PAN ASSEMBLY | ||
| 13 | XA4466 | SEAT BACK CUSHION ASSEMBLY | ||
| 14 | XA4467 | SEAT CUSHION ASSEMBLY | ||
| 15 | XA4454 | FLAT WASHER-M8 | ||
| 16 | XA4455 | LOCKNUT-M8 | 4 | |
| 17 | XA4451 | SCREW,TORX-3/8"×3/4" | 4 | |
| 18 | XA4452 | FLAT WASHER-3/8" | 4 | |
| 19 | XA4453 | CAPSCREW-7/16"X1" | 2 | |
| NS | NOTE:(1)NOT PART OF SEATASSEMBLY. | |||
| CAB GROUP | ||||
| PASSENGER SEAT INSTALLATION | ||||
| ltem | Part No | Description | Qty | Ref |
| 1 PC2550 SEAT ASSEMBLY,PASSENGER(SEE INDEX)1 42464 | ||||
| 2 TD0794 CAPSCREW-5/16"-18NC×3/4" 4 | ||||
| 3 SC4174 LOCKWASHER-5/16" 4 | ||||
| 4 TV0177 FLAT WASHER-5/16" 4 | ||||
| CAB GROUP | ||||
| SEAT ASSEMBLY 2/258E-57-00501 | ||||
| Item | Part No | Description | Qty | |
| 1 | 58E-98-10210 | SEAT BELT(3-POINT) | 1 | |
| 2 | 58E-98-10370 | CAPSCREW-M12×1.75×30 | 1 | |
| 3 | EM4065 | FLAT WASHER(HARDENED) | 1 | |
| 4 | 58E-98-10100 | UPPER MOUNT,SEAT BELT | 1 | |
| 5 | 58E-98-10360 | CAPSCREW-3/8"-16NC×11/2" | 4 | |
| 6 | XA4070 | FLAT WASHER | 4 | |
| 7 | XA4962 | NUT,CENTERLOCK-3/8”-16NC | 6 | |
| 8 | 58E-98-10160 | ARMREST PAD-R.H. | ||
| 9 | 58E-98-10180 | ARM &BRACKETASSEMBLY-R.H. | ||
| 10 | 58E-98-10170 | ARMREST PAD-L.H. | ||
| 11 | 58E-98-10190 | ARM &BRACKETASSEMBLY-L.H. | 1 | |
| 12 | 58E-98-10350 | CAPSCREW-M8×1.25×30 | 2 | |
| 13 | 58E-98-10340 | FLAT WASHER | 4 | |
| 14 | XA4963 | FLAT WASHER | 4 | |
| 15 | 58E-98-10290 | PLUG | 2 | |
| 16 | EM4063 | SWITCH,VALVE-SEAT RAISE/LOWER | 1 | |
| 17 | 58E-98-10380 | CAPSCREW-M8×1.25×20 | 2 | |
| 18 | EM4061 | KITBELT TETHER | 2 | |
| 19 | XA4844 | PIN,COTTER | 2 | |
| 20 | PB9772 | EYEBOLT | 2 | |
| 21 | TG3941 | JAM NUT(1) | 2 | |
| 22 | XA5121 | BOLT,CARRIAGE-7/16"-14NC | ||
| 23 | XA4072 | FLAT WASHER | ||
| 24 | XA5118 | NUT,CENTERLOCK-7/16"-14NC | ||
| 25 | 58E-98-10260 | CAPSCREW-M10×1.50×20 | ||
| 26 | 58E-98-10220 | SUPPORT PLATE,RETRACTOR | ||
| 27 | 58E-98-10270 | NUT,FLANGE-M12×1.75 | ||
| 28 | XA4073 | CAPSCREW-M12×1.75×50 | ||
| 29 | 58E-98-10310 | SCREW-1/4"×3/4" | 2 | |
| 30 | EM4075 | FLAT WASHER | ||
| 31 | 58E-98-10320 | LOCKNUT-M10×1.50 | ||
| NS | NOTE:(1)NOT PART OF SEAT ASSEMBLY. | |||
