| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| HEATER/AIR CONDITIONER DASH MODULE | ||||
| Item | Part No | Description | Qty | |
| 1 | PB8658 | SCREW-M6×1.00×30 | 6 | |
| 2 | EL1060 | PANEL,MOLDED | 1 | |
| 3 | SM2406 | SCREW,SELF-TAPPING-#6-32NCX3/8" | 6 | |
| 4 | PB8319 | LOUVER | 3 | |
| 5 | EK7943 | ADAPTER,HOSE | 3 | |
| 6 | EK8966 | MOUNT,TOP DASH | 1 | |
| 7 | HC0920 | CLAMP,WORM DRIVE | 6 | |
| 8 | EK7941 | HOSE | 3 | |
| 9 | EK5507 | BLOCK | 1 | |
| 10 | MM0357 | MACHINE SCREW-M6×1.00×12 | 2 | |
| 11 | TR1307 | FLAT WASHER-1/4" | 2 | |
| 12 | XB0400 | BAR | 1 | |
| 13 | SM2682 | SCREW,COUNTERSUNK | 4 | |
| 14 | XB0402 | PLATE | 1 | |
| 15 | 58F-54-00040 | SCREW,COUNTERSUNK | 3 | |
| 16 | SM0926 | SCREW-M6×1.00 | 4 | |
| HEATERIAIR CONDITIONER ASSEMBLY 2/258F-07-00030 | ||||
| ltem | Part No | Description | Qty | |
| 1 | EM0053 | BLOWER ASSEMBLY | 1 | |
| 2 | EM0094 | BLOWER RETAINER | 1 | |
| 3 | EM0067 | SCREW | 2 | |
| 4 | EM0052 | HEATER CORE | 1 | |
| 5 | EM0051 | EVAPORATOR CORE | 1 | |
| 6 | EM0083 | SCREW | 6 | |
| 7 | EM0060 | ACTUATOR | 2 | |
| 8 | EM0075 | BRACKET | 1 | |
| 9 | EM0089 | DRIVE ADAPTER | 2 | |
| 10 | EM0086 | PIVOT BUSHING | 2 | |
| 11 | EM0091 | DAMPER DOOR(SIDE) | 1 | |
| 12 | EM0073 | BRACKET | 1 | |
| 13 | EM0090 | DAMPER DOOR(UP) | 1 | |
| 14 | EM0072 | FOAM | 2 | |
| 15 | EM0071 | FOAM | 1 | |
| 16 | 58F-98-00050 | THERMOSTAT | 1 | |
| 17 | 58D-98-00010 | SCREW | 2 | |
| HVAC VENTS | ||||
| Item | Part No | Description | Qty | |
| 1 PB8319 LOUVER 8 | ||||
| 2 PB8320 ADAPTER 8 | ||||
| 3 SG2106 SCREW,SELF TAPPING-#6-32NC×1/2"16 | ||||
| CONTROL PANEL SWITCH EL5676 | ||||
| Item | Part No | Description | Qty | |
| 1 | XA4474 | KNOB,CONTROL | 3 | |
| 2 | XA4476 | NUT-7/16"-28NF | 3 | |
| 3 | XA4475 | LABEL,CONTROL PANEL | 1 | |
| 4 | XA4477 | PANEL,CONROL | 1 | |
| 5 | XA4480 | SWITCH,3 SPEED ROTARY | ||
| 6 | XA4478 | RESISTOR,VARIABLE | ||
| 7 | XA4479 | SWITCH,ROTARY (W/NUTS) | ||
| 8 | XA4481 | BRACKET,LAMP | ||
| HEATERIAIR CONDITIONER ASSEMBLY 1/258F-07-00030 | ||||
| ltem | Part No | Description | Qty | Ref |
| 1 | EL5797 | VALVE,WATER | 1 | |
| 2 | EM0093 | PUNCHED STRIP | 1 | |
| 3 | EM0082 | SEAL | 2 | |
| 4 | EM0092 | PUNCHED STRIP | 1 | |
| 5 | EM0067 | SCREW | 15 | |
| 6 | EM0085 | BULB | 2 | |
| 7 | EL5676 | CONTROLPANEL.SWITCH (SEE INDEX) | 1 | 51012 |
| 8 | EM0076 | HARNESS,CONTROL PANEL | 1 | |
| 9 | XA4433 | COVER | 1 | |
| 10 | EM0069 | KNOB | 2 | |
| 11 | EM0054 | RECIRCULATION GRILLE-OUTER | 1 | |
| 12 | EM0055 | RECIRCULATION FILTER | 1 | |
| 13 | EM0056 | RECIRCULATION GRILLE-INNER | 1 | |
| 14 | EM0070 | SEAL | 1 | |
| 15 | EM0087 | PUNCHED STRIP | 1 | |
| 16 | EM0065 | SEAL-TOP | 1 | |
| 17 | EM0063 | SEAL-L.H | 1 | |
| 18 | 58F-98-00040 | EXPANSION BLOCK VALVE | 1 | |
| 19 | EM0078 | HARNESS,MAIN UNIT | 1 | |
| 20 | EM0064 | SEAL-FRONT | 1 | |
| 21 | EM0059 | RELAY | 3 | |
| 22 | EM0084 | SCREW | 3 | |
| 23 | EM0088 | GROMMET | 1 | |
| 24 | EM0074 | CASE | 1 | |
