Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| CAB GROUP | ||||
| UPPER RH DASH MODULE XB8077 | ||||
| Item | Part No | Description | Qty | |
| 1 | WA4605 | SCREW-#10-24NCX1/2" | 4 | |
| 2 | EL3143 | DECAL | 1 | |
| 3 | EL3144 | PLATE,MOUNTING | 1 | |
| 4 | PC0493 | SWITCH,HAZARD LIGHTS | 1 | |
| 5 | PC2648 | SWITCH,BRAKE TEST | 1 | |
| 6 | 1439428H1 | PLUG | 2 | |
| 7 | PC1766 | SWITCH,WHEEL BRAKE LOCK | 1 | |
| HEATER PIPING | ||||
| Item | Part No | Description | Qty | |
| 1 | TV2642 | FITTING,ELBOW | 2 | |
| 2 | HC0908 | CLAMP,WORM DRIVE | 4 | |
| 3 | MM0461 | FLAT WASHER-M10 | 5 | |
| 4 | MM0471 | LOCKWASHER-M10 | 5 | |
| 5 | MM0178 | NUT-M10×1.50 | 5 | |
| 6 | WB3092 | CLAMP,CUSHIONED-7/8" | 17 | |
| 7 | KC1255 | CLAMP,U-BOLT(66.5 MM) | 5 | |
| 8 | JG8379 | HOSE,HEATER | 2 | |
| 9 | VD6174 | CLAMP,U-BOLT(93.2 MM) | 2 | |
| 10 | VN6280 | VALVE,SHUTOFF | 2 | |
| 11 | SD5209 | BUSHING | 2 | |
| 12 | PC1780 | ADAPTER | 2 | |
| 13 | MM0605 | CAPSCREW-M10×1.50×25 | 1 | |
| BODY PIVOT | ||||
| Item | Part No | Description | Qty | uom |
| 1 | EM8112 | SHOULDER BOLT-11/8”-7NC×91/2”(1) | 2 | |
| 2 | ED0569 | PIN,BODY PVOT(1) | 2 | |
| 3 | WA0365 | FLAT WASHER-114"(1) | 4 | |
| 4 | PC3201 | LOCKNUT-11/8”-7NC(1) | 2 | |
| 5 | EF0745 | BUSHING,BODY PIVOT-INNER(1) | 2 | |
| 6 | TY8820 | BUSHING,PIVOT(1) | 2 | |
| 7 | TY9293 | SHIM(1) | ASREQUIRED | |
| 8 | ED7962 | BUSHING,BODY PIVOT-OUTER(1) | 2 | |
| NS | AK5666 | NOTE:(1)INCLUDED INAK5666 BODY PIVOTPIN KIT | ||
| WIPERNASHER TIMER DELAY MODULES | ||||
| Item | Part No | Description | Qty | |
| 1 | 58E-06-00610 | HARNESS,CAB DASH | 1 | |
| 2 | PC2834 | DIODE-4 AMP | 3 | |
| 3 | PC1730 | RELAY | 2 | |
| 4 | PC0566 | MODULE,WIPER TIMER DELAY | 1 | |
| 5 | PC1838 | MODULE,WASHER TIMER DELAY | 1 | |
| 6 | MM0459 | FLAT WASHER-M6 | 4 | |
| 7 | MM0357 | MACHINE SCREW-M6×1.00×12 | 4 | |
| 8 | MM0353 | MACHINE SCREW-M5X.8×30 | 1 | |
| 9 | MM0379 | LOCKWASHER-M5 | 5 | |
| 10 | MM0348 | MACHINE SCREW-M5X.8×10 | 2 | |
| 11 | WB0816 | NAME PLATE-WRH | 1 | |
| 12 | WB0817 | NAME PLATE-WRL | 1 | |
| 13 | WB0818 | NAME PLATE-WADT | 1 | |
| 14 | WB0819 | NAME PLATE-WIDT | 1 | |
| 15 | MM0595 | CAPSCREW-M8×1.25×30 | 2 | |
| 16 | MM0470 | LOCKWASHER-M8 | 2 | |
| 17 | EL1698 | BRACKET | 1 | |
| 18 | XC0105 | PLATE,SWITCHER | 1 | |
| WINDSHIELD WASHER INSTALLATION | ||||
| Item | Part No | Description | Qty | |
| 0 | PB7514 | WNDSHIELD WASHER ASSEMBLY | 1 | |
| 1 | VE2942 | CAP | ||
| 2 | VE5339 | TANK | ||
| 3 | VE2941 | PUMP | 1 | |
| 4 | VE6598 | GROMMET | 1 | |
| 5 | MM0176 | NUT-M6×1.00 | 5 | |
| 6 | MM0469 | LOCKWASHER-M6 | 5 | |
| 7 | VF6144 | FLAT WASHER-1/4" | 5 | |
| 8 | PC2145 | VALVE,CHECK | 1 | |
| 9 | VN0137 | CLAMP,CUSHION-7/16" | 2 | |
| 10 | EG3904 | HOSE | 1 | |
| 11 | SL9490 | GROMMET,RUBBER | 1 | |
| WIPER LINKAGE ASSEMBLY PB9926 | ||||
| Item | Part No | Description | Qty | |
| 1 | XA5139 | CRANK,MOTOR | 1 | |
| 2 | XA2892 | SPINDLE(RH) | 1 | |
| 3 | XA2893 | SPINDLE(LH) | 1 | |
| 4 | XA2891 | LINK (LH) | 1 | |
| 5 | XA2890 | LINK (RH) | ||
| WINDSHIELD WIPER/WASHER INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | PB9923 | MOTOR,WIPER-24VOLT | 1 | |
| 2 | MM0592 | CAPSCREW-M8×1.25X16 | 5 | |
| 3 | MM0712 | FLAT WASHER-M8 | 14 | |
| 4 | MM0470 | LOCKWASHER-M8 | 5 | |
| 5 | SM4345 | PLATE | 1 | |
| 6 | MM0581 | CAPSCREW-M6X1.00X16 | 3 | |
| 7 | MM0711 | FLAT WASHER-M6 | 3 | |
| 8 | MM0469 | LOCKWASHER-M6 | 3 | |
| 9 | PB9926 | WIPER LINKAGE ASSEMBLY (SEE INDEX) | 1 | 42777 |
| 10 | PC1823 | ARM,WIPER | 2 | |
| 11 | XA2095 | NOZZLE | 2 | |
| 12 | PB9925 | BLADE,WIPER | 2 | |
| 13 | MM0022 | CAPSCREW-M8×1.25X20 | 4 | |
| 14 | MM0460 | FLAT WASHER-M8 | 4 | |
| 15 | EG0735 | TEE,HOSE | 1 | |
| 16 | TF6380 | GROMMET,RUBBER | 2 | |
| 17 | SM4477 | HOSE | 2 | |
| 18 | EG3904 | HOSE | 1 | |
| 19 | NUT-M8×1.25(1) | 1 | ||
| 20 | COVER(1) | 1 | ||
| 21 | NUT-M20×1.00(1) | 1 | ||
| 22 | WASHER(1) | 1 | ||
| 23 | WASHER(1) | |||
| NS | XA3071 | NOTE:(1)NOT SVCD SEPARATELY.ORDER XA3071 HARDWARE KIT. | ||
| HEATERIAC DRAIN HOSE INSTALLATION | ||||
| Item | Part No | Description | Qty | |
| 1 | TH7023 | NIPPLE,LONG-1/2"NPTX7" | 1 | |
| 2 | SL6447 | GROMMET | 1 | |
| 3 | R5011 | ELBOW | 1 | |
| 4 | KC3835 | FITTING | ||
| 5 | HC0908 | CLAMP,WORM DRIVE | ||
| 6 | HK0425 | HOSE | ||
| 7 | SM6023 | TUBE | ||
| 8 | SM6022 | VALVE,VACUUM | 1 | |
| 9 | WB3093 | CLAMP,CUSHIONED-1" | 5 | |
| 10 | MM0178 | NUT-M10×1.50 | 5 | |
| 11 | MM0471 | LOCKWASHER-M10 | 5 | |
| 12 | MM0461 | FLAT WASHER-M10 | 5 | |
