Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| CONTROL GROUP MODEL17KG535B1 See On-Line Master for Current Revision |
|||
| PART NO. | QTY | DESCRIPTION | |
| 41A256621P1 | 1 | BASE,41/2 IN LONG,3/4 IN THICK | |
| 41A279870P36 | 12 | STUD,5/8 IN-11,161/4 IN LONG | |
| 17FM681A1 | 4 | PANEL ASSEMBLY(VAM) | |
| 41A326243P2 | 2 | INSULATOR,2 INLONG | |
| N22P23044B13 | AR | BOLT,HEX HD,5/16IN-18,23/4 INLONG | |
| N22P23040B13 | AR | BOLT,HEX HD,5/16IN-18,21/2 IN LONG | |
| N402AP42B13 | AR | WASHER,5/16 IN | |
| N22P25088B13 | 2 | BOLT,HEX HD,3/8 IN-16,51/2 INLONG | |
| 41A250668P116 | AR | WASHER,11/16IN | |
| 41B537660P2 | AR | WASHER,FLAT,0.435 INID,1.188 IN OD | |
| N22P25028B13 | AR | BOLT,HEX HD,3/8 IN-16,13/4 INLONG | |
| N405P43B13 | AR | LOCKWASHER,3/8 IN | |
| N402P43B13 | AR | WASHER,3/8 IN | |
| N258P25B13 | AR | NUT,HEX,3/8 IN-16 | |
| N402P15B13 | AR | WASHER,0.50 IN,NARROW | |
| N405P45B13 | AR | LOCKWASHER,0.50 IN | |
| N258P29B13 | AR | NUT,HEX,1/2 IN-13 | |
| N405P42B13 | AR | LOCKWASHER,5/16 IN | |
| N258P23B13 | AR | NUT,HEX,5/16 IN-18 | |
| N402P45B13 | AR | WASHER,1/2 IN(NARROW) | |
| 41A279870P46 | 60 | STUD,1/2 IN-13,123/4 IN LONG | |
| N402P39B13 | AR | WASHER,NO 10 | |
| N405P39B13 | AR | LOCKWASHER,NO 10 | |
| N210P16B13 | AR | NUT,HEX,NO10-32 | |
| 84B521625G1 | 10 | PLATE ASSEMBLY | |
| 41B537660P7 | AR | WASHER,FLAT,0.562 INID,1.250 IN OD | |
| 84A214673P1 | 2 | LENS CAP | |
| 41A250243P66 | 8 | WASHER,1/2 IN OD,1/2 IN THICK | |
| N22P25032B13 | 13 | BOLT,HEX HD,3/8 IN-16,2 INLONG | |
| N668P16016B13 | 6 | SCREW,SLHEX HD,NO 10-32,1 IN LONG | |
| N402P41B13 | AR | WASHER,1/4IN | |
| N405P41B13 | AR | LOCKWASHER,1/4 IN | |
| N258P21B13 | AR | NUT,HEX,1/4 IN-20 | |
| N22P21020B13 | 6 | BOLT,HEX HD,1/4IN-20,11/4 INLONG | |
| 41C662412G2 | 1 | FILTER PANEL ASSEMBLY | |
| 41B564487G1 | 3 | RESISTORASSEMBLY | |
| 482A444BXP3 | 6 | RESISTOR,200 WATT,25 OHM | |
| 41B566749G1 | 3 | CAPACITORASSEMBLY | |
| N668P16026B13 | 2 | SCREW,SLHEX HD,NO 10-32,15/8 INLONG | |
| N22P29040B13 | 6 | BOLT,HEX HD,1/2 IN-13,21/2 INLONG | |
| N668P16012B13 | AR | SCREW,SLHEX HD,NO 10-32,3/4 IN LONG | |
| 84D708749G1 | 3 | BASE ASSEMBLY | |
| 17FM792A2 | 3 | RECTIFIERPANEL,IGBT | |
| N89P16022B13 | 2 | STUD,NO 10-32,13/8 INLONG | |
| 84B515891P2 | 1 | SUPPORT,6IN LONG | |
| 84B519628P1 | 6 | BUS BAR,0.375 IN THICK | |
| 84B519629P1 | 6 | BUS BAR,0.375 INTHICK | |
| 84B519630P1 | 2 | BUS BAR,0.50 IN THICK | |
| 84B523516P1 | 1 | BUS BAR,0.625 IN THICK | |
| CONTROL GROUP MODEL17KG535B1 See On-Line Master for Current Revision |
|||
| PART NO. | QTY | DESCRIPTION | |
| 84B519704P1 | 1 | BUS BAR,INSULATED,0.625 IN THICK | |
| 84B519705P1 | 1 | BUS BAR,15.75 INLONG | |
| 84B519703P1 | 1 | BUS BAR,0.625 INTHICK | |
| 84B519636P1 | 2 | BUS BAR,0.50 INTHICK | |
| 84B522108P1 | 1 | BUS BAR,0.187 INTHICK | |
| 84B520976P1 | 1 | BUS BAR,0.50 INTHICK | |
| 84B519639P1 | 1 | BUS BAR,0.625 IN THICK | |
| 84C604236P1 | BUS BAR,0.625 INTHICK,51.38 INLONG | ||
| 84C604237P1 | BUS BAR,0.625 INTHICK,55.29 INLONG | ||
| 84D713467P1 | BUS BAR,1 INTHICK | ||
| 84D713468P1 | BUS BAR,INSULATED,1 INTHICK | ||
| 84B523519P1 | BUS BAR,0.62 INTHICK,17.5 INLONG | ||
| 84B523520P1 | BUS BAR,1 IN THICK,13INLONG | ||
| 84B519647P1 | 1 | BUS BAR,0.50 INTHICK | |
| 84B520976P1 | 4 | BUS BAR,0.50 INTHICK | |
| 84B520977P1 | 5 | BUS BAR,0.50 INTHICK | |
| 41A314471P1 | 1 | BUS BAR,0.250 INTHICK | |
| 84B519804P1 | 2 | BUS BAR,0.375 INTHICK | |
| 84B519786P1 | 2 | BUS BAR WITH BOLT(BRAZE IN N22P25020B13),0.250 IN THICK | |
| 41A279870P2 | 12 | STUD,1/2 IN-13,3 IN LONG | |
| 41A260128P1 | 38 | INSULATOR,1/2 IN-13 THREADS,BOTH ENDS | |
| 41A327044G2 | 2 | INSULATOR ASSEMBLY,31/8 IN LONG | |
| 41A296332BLP2 | 5 | VERTICAL BUS BAR | |
| 41A296332BLP13 | 5 | BUS BAR,IGBT | |
| N22P23048B13 | 4 | BOLT,HEX HD,5/16 IN-18,3 INLONG | |
| 41A326243P2 | 2 | INSULATOR,2 INLONG | |
| 41A250106P55 | 4 | GROMMET,117/64 IN ID,RUBBER | |
| N22P29044B13 | 4 | BOLT,HEX HD,1/2 IN-13,23/4 INLONG | |
| 41A327438P1 | 1 | SHIELD,51/4 IN WIDE,61/2 IN LONG,GLASTIC | |
| 41A279870P15 | 12 | STUD,1/2 IN-13,21/2 INLONG | |
| 41A279870P8 | 16 | STUD,1/2 IN-13,21/4 INLONG | |
| 41A257639P5 | AR | CEMENT | |
| 84B517090P1 | 1 | SHIELD,7.5 INX30.38 IN | |
| 84B520956G1 | 4 | BRACKET ASSEMBLY | |
| N22P23016B13 | 10 | BOLT,HEX HD,5/16 IN-18,1INLONG | |
| N402P13B13 | 13 | WASHER,3/8 IN(NARROW) | |
| N22P25024B13 | AR | BOLT,HEX HD,3/8 IN-16,11/2 INLONG | |
| N22P29036B13 | AR | BOLT,HEX HD,1/2 IN-13,21/4 INLONG | |
| 41A250106P26 | 7 | GROMMET,RUBBER,7/8 INID | |
| 41A250106P45 | 4 | GROMMET,11/2 IN ID,21/8 IN OD,RUBBER | |
| 41C667531G3 | 2 | CAPACITORASSEMBLY | |
| 41A324439G6 | 2 | RESISTOR WITH TERMINALS | |
| N22P25016B13 | AR | BOLT,HEX HD,3/8 IN-16,1 INLONG | |
| 84B518896G1 | 1 | RESISTOR | |
| 84A214674P1 | 2 | ADAPTER | |
| 41A216940P1 | 2 | LOCK RING,0.97 INID | |
| 84B519581ABG1 | 1 | BASE ASSEMBLY | |
| N22P25040B13 | 4 | BOLT,HEX HD,3/8 IN-16,21/2 INLONG | |
| N22P25028B13 | 11 | BOLT,HEX HD,3/8 IN-16,13/4 INLONG | |
| N430P3 | 6 | WASHER,HARDENED,3/8 IN | |
| N402P9B13 | AR | WASHER,NO 10(NARROW) | |
| N402P11B13 | 4 | WASHER,1/4 IN(NARROW) | |
| N22P21014B13 | 6 | BOLT,HEX HD,1/4IN-20,7/8 IN LONG | |
| 41A250668P71 | 10 | WASHER,0.406 ID | |
| N22P29016B13 | 10 | BOLT,HEX HD,1/2 IN-13,1 INLONG | |
| 41A279870P28 | 2 | STUD,3/8 IN-16,23/4 INLONG | |
